Anchor Block

{
  "view": "Detail",
  "objects": [
    {
      "name": "plate, bolt-hole pattern",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": null,
      "note": ""
    },
    {
      "name": "block, bottom",
      "tag": "510A",
      "shape": "rectangular",
      "material": "",
      "count": 1,
      "note": ""
    }
  ],
  "measurements": [
    {
      "label": "width",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "plate"
    }
  ],
  "notes": [],
  "labels": [],
  "description": "Detail view of a tall rectangular plate with a vertical pattern of bolt holes and a bottom attached block labeled 510A. The plate width is 1'-0\". The crop focuses on the bolt-hole pattern portion and its associated bottom element."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "Rectangular hollow post / box section",
      "tag": "",
      "shape": "rectangular hollow",
      "material": "",
      "count": 1,
      "note": "long slender member with bolt holes along inner face"
    },
    {
      "name": "Anchor block",
      "tag": "540A",
      "shape": "rectangular block",
      "material": "",
      "count": 1,
      "note": ""
    }
  ],
  "measurements": [
    {
      "label": "width",
      "value": "1'-0\"",
      "unit": "ft",
      "appliesTo": "Rectangular hollow post"
    }
  ],
  "notes": [],
  "labels": [
    "5-43A EA. FAS. AT Eq. SPS."
  ],
  "description": "Detail view showing a tall rectangular hollow member with a line of bolt holes along its inner face and an attached lower anchor block labeled 540A; a width of 1'-0\" is indicated at the top."
}
