Chamfer

1 page · 1 crop · ×1 · superstructure

⚠ No class in the bridge ontology fits this itemAdd a class

The ontology would need a concrete chamfer class.

Notes on the sheets that carry it

  • p5NO SCALE

Every crop it was read in — the drawing beside what the model took off it

Page 5

crop

p05_r02

page 5 · other_p05_r02
Original
p05_r02
{
  "view": "Detail",
  "objects": [
    {
      "name": "CHAMFER",
      "tag": "",
      "shape": "edge bevel",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "PREFORMED JOINT FILLER",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "LOW MODULUS SILICONE SEALANT (TYPE A)",
      "tag": "",
      "shape": "sealant bead",
      "material": "low modulus silicone",
      "count": 1,
      "note": ""
    },
    {
      "name": "BARRIER",
      "tag": "",
      "shape": "trapezoidal/building barrier section",
      "material": "",
      "count": 1,
      "note": ""
    }
  ],
  "measurements": [
    {
      "label": "CHAMFER",
      "value": "3/4",
      "unit": "in",
      "appliesTo": "PLAN"
    },
    {
      "label": "PREFORMED JOINT FILLER",
      "value": "1",
      "unit": "in",
      "appliesTo": "PLAN / ELEVATION"
    },
    {
      "label": "BASE WIDTH",
      "value": "3",
      "unit": "in",
      "appliesTo": "SIDE ELEVATION"
    }
  ],
  "notes": [
    "NO SCALE"
  ],
  "labels": [
    "PLAN",
    "ELEVATION",
    "SIDE ELEVATION",
    "DETAILS OF 1 EXPANSION JOINT IN BARRIER",
    "NO SCALE"
  ],
  "description": "Detail showing the expansion joint in a barrier with plan, elevation, and side elevation views. Features include a 3/4 inch chamfer, 1 inch preformed joint filler, and low modulus silicone sealant (Type A). No scale."
}

p05_r02Detail

  • CHAMFER×1edge bevel

3/4 in CHAMFER1 in PREFORMED JOINT FILLER3 in BASE WIDTH
