Construction Joint

{
  "view": "Detail",
  "objects": [
    {
      "name": "Bar - main slab reinforcement",
      "tag": "",
      "shape": "line",
      "material": "reinforcing steel",
      "count": null,
      "note": "vertical reinforcement bars labeled MAIN SLAB REINF."
    },
    {
      "name": "Bar 500B",
      "tag": "*500B",
      "shape": "line",
      "material": "reinforcing steel",
      "count": 1,
      "note": "star-marked 500B bar"
    },
    {
      "name": "Construction joint line",
      "tag": "",
      "shape": "line (diagonal)",
      "material": "",
      "count": null,
      "note": "B.F.P.R. OR CONST. JOINT"
    },
    {
      "name": "Diagonal joint detail line",
      "tag": "",
      "shape": "line (diagonal, dashed)",
      "material": "",
      "count": null,
      "note": ""
    }
  ],
  "measurements": [
    {
      "label": "2\" CL.",
      "value": "2",
      "unit": "in",
      "appliesTo": ""
    }
  ],
  "notes": [
    "BARS ARE DETAILED IN BAR DETAILS AS EQUIVALENT FULL LENGTH BARS.",
    "* SEE SUBSECTION 5I.3.05.G.5 OF THE GEORGIA DOT SPECIFICATION FOR PLACEMENT OF 500B BAR."
  ],
  "labels": [
    "BAR BENDING DETAILS AT SKEWED JOINTS",
    "NO SCALE",
    "AT B.F.P.R. OR CONST. JOINT",
    "MAIN SLAB REINF."
  ],
  "description": "Detail view of a circular bar-bending detail for skewed joints, showing main slab reinforcement, a 500B bar, and a construction joint line labeled B.F.P.R. OR CONST. JOINT. Includes a 2 in. clear dimension and notes referencing Georgia DOT specs."
}

{
  "view": "Section",
  "objects": [
    {
      "name": "ENDWALL",
      "tag": "",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": "3'-0\" ENDWALL"
    },
    {
      "name": "PREFORMED JOINT FILLER",
      "tag": "",
      "shape": "block",
      "material": "foam/joint filler",
      "count": 1,
      "note": "L 1/2\" PREFORMED JOINT FILLER, TYP."
    },
    {
      "name": "ENDWALL",
      "tag": "",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": "1'-6\" ENDWALL"
    },
    {
      "name": "PREFORMED JOINT FILLER",
      "tag": "",
      "shape": "block",
      "material": "foam/joint filler",
      "count": 1,
      "note": "L 1/2\" PREFORMED JOINT FILLER, TYP."
    },
    {
      "name": "PREFORMED FOAM JOINT FILLER",
      "tag": "",
      "shape": "block",
      "material": "foam",
      "count": 1,
      "note": "1\" PREFORMED FOAM JOINT FILLER AROUND PAD, TYP."
    },
    {
      "name": "BARRIER",
      "tag": "",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": ""
    },
    {
      "name": "SLAB",
      "tag": "",
      "shape": "rectangular",
      "material": "concrete",
      "count": 1,
      "note": "SLAB"
    },
    {
      "name": "PULL POST",
      "tag": "",
      "shape": "cylindrical",
      "material": "steel",
      "count": 1,
      "note": "2 7/8\" PULL POST"
    },
    {
      "name": "END POST",
      "tag": "",
      "shape": "cylindrical",
      "material": "steel",
      "count": 1,
      "note": "END POST"
    },
    {
      "name": "FENCE",
      "tag": "",
      "shape": "mesh",
      "material": "galvanized steel",
      "count": 1,
      "note": "ZINC COATED FENCE"
    },
    {
      "name": "POST VERT.",
      "tag": "",
      "shape": "rectangular",
      "material": "steel",
      "count": 1,
      "note": "VERTICAL POST ZINC COATED"
    },
    {
      "name": "CONSTR. JOINT",
      "tag": "",
      "shape": "joint",
      "material": "concrete",
      "count": 1,
      "note": "CONSTR. JOINT"
    }
  ],
  "measurements": [
    {
      "label": "34'-0\"",
      "value": "34'-0\"",
      "unit": "",
      "appliesTo": "top dimension"
    },
    {
      "label": "6'-8\"",
      "value": "6'-8\"",
      "unit": "",
      "appliesTo": "top right dimension"
    },
    {
      "label": "3'-0\" ENDWALL",
      "value": "3'-0\" ENDWALL",
      "unit": "",
      "appliesTo": "left endwall"
    },
    {
      "label": "1'-6\" ENDWALL",
      "value": "1'-6\" ENDWALL",
      "unit": "",
      "appliesTo": "middle endwall"
    },
    {
      "label": "2% slope",
      "value": "2%",
      "unit": "",
      "appliesTo": "section slope"
    }
  ],
  "notes": [
    "FENCE NOTES:",
    "1. FENCE SHALL BE 9 GAGE CHAIN LINK ZINC COATED TWO INCH SECURITY FENCE.",
    "2. CAST 4\" DIA. GALVANIZED SLEEVE IN THE PARAPET. ALLOW NON-SHRINK, NON-METALLIC GROUT TO CURE FOR THREE DAYS BEFORE FENCE FABRIC IS INSTALLED.",
    "3. APPLY GALVANIZING REPAIR COMPONENT, IN ACCORDANCE WITH GEORGIA DOT SPECIFICATIONS SECTIONS 645, TO ENDS OF 4\" DIA. GALVANIZED SLEEVES."
  ],
  "labels": [
    "SECTION THRU ENDWALL"
  ],
  "description": "This crop is a Section through an endwall and associated barrier assembly, showing endwalls at multiple locations, a barrier, posts, tension bars, a zinc-coated fence, and the adjacent concrete slab. It includes notes on joint fillers and fence installation as part of the endwall detail."
}
