Hex nut

{
  "view": "Notes",
  "objects": [
    {
      "name": "Diaphragm bar",
      "tag": "",
      "shape": "circular",
      "material": "reinforcing steel (plain bar)",
      "count": 1,
      "note": "1\" diameter; threaded 5\" on each end"
    },
    {
      "name": "Washer",
      "tag": "",
      "shape": "circular",
      "material": "steel washer",
      "count": null,
      "note": "1/4\" x 3/2\" diameter washers"
    },
    {
      "name": "Hex nut",
      "tag": "",
      "shape": "circular",
      "material": "steel",
      "count": null,
      "note": "hex nuts (ASTM A 709 GRADE 36)"
    },
    {
      "name": "Epoxy grout",
      "tag": "",
      "shape": "bulk",
      "material": "epoxy grout",
      "count": null,
      "note": "exposed in recess after painting"
    },
    {
      "name": "Protective coating No. 2P",
      "tag": "",
      "shape": "layer",
      "material": "protective coating",
      "count": null,
      "note": "special protective coating No. 2 P as per section 535"
    },
    {
      "name": "Galvanizing (not complete)",
      "tag": "",
      "shape": "process",
      "material": "galvanizing",
      "count": null,
      "note": "GALVANIZING OF THE DIAPHRAGM BAR AS PER SUB-SECTION 865.2.0I.B.12 OF THE GEORGIA DOT SPECIFICATIONS IS NOT"
    }
  ],
  "measurements": [
    {
      "label": "Diaphragm bar diameter",
      "value": "1\"",
      "unit": "in",
      "appliesTo": "Diaphragm bar"
    },
    {
      "label": "Thread length",
      "value": "5\"",
      "unit": "in",
      "appliesTo": "Diaphragm bar"
    },
    {
      "label": "Washer size",
      "value": "1/4\" x 3/2\"",
      "unit": "in",
      "appliesTo": "Washer"
    }
  ],
  "notes": [
    "DIAPHRAGM BAR SHALL BE A 1\" DIAMETER PLAIN BAR, THREADED 5\" ON EACH END, WITH 1/4\" X 3/2\" DIAMETER WASHERS AND HEX NUTS (ASTM A 709 GRADE 36).",
    "TIGHTEN DIAPHRAGM BAR AS PER SUB-SECTION 507.3.05.C OF THE GEORGIA DOT SPECIFICATIONS.",
    "AFTER EXCESS DIAPHRAGM BAR HAS BEEN CUT OFF, PAINT DIAPHRAGM BAR, WASHER, AND NUT EXPOSED IN RECESS WITH SPECIAL PROTECTIVE COATING NO. 2 P AS PER SECTION 535 OF THE GEORGIA DOT SPECIFICATIONS. AFTER PAINTING, FILL THE RECESS WITH AN APPROVED EPOXY GROUT.",
    "GALVANIZING OF THE DIAPHRAGM BAR AS PER SUB-SECTION 865.2.0I.B.12 OF THE GEORGIA DOT SPECIFICATIONS IS NOT"
  ],
  "labels": [],
  "description": "Crop shows a notes block detailing diaphragm bar fabrication and finishing per Georgia DOT specs: 1 inch diameter plain bar with 5 inch thread ends, washers and nuts, coating No. 2P, epoxy grout fill, and a note on galvanizing."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "Diaphragm bar",
      "tag": "",
      "shape": "circular",
      "material": "plain steel",
      "count": 1,
      "note": ""
    },
    {
      "name": "Washer",
      "tag": "",
      "shape": "circular",
      "material": "metal",
      "count": 1,
      "note": ""
    },
    {
      "name": "Hex nut",
      "tag": "",
      "shape": "hexagonal",
      "material": "steel (ASTM A 709 Grade 36)",
      "count": 2,
      "note": ""
    },
    {
      "name": "Hole",
      "tag": "",
      "shape": "circular",
      "material": "drilled",
      "count": 1,
      "note": "2\" DIAMETER HOLE"
    }
  ],
  "measurements": [
    {
      "label": "1\" CL.",
      "value": "1",
      "unit": "in",
      "appliesTo": ""
    },
    {
      "label": "3\"",
      "value": "3",
      "unit": "in",
      "appliesTo": ""
    },
    {
      "label": "2\" DIAMETER HOLE",
      "value": "2",
      "unit": "in",
      "appliesTo": "Hole"
    },
    {
      "label": "CUT OFF EXCESS DIAPHRAGM BAR",
      "value": "1",
      "unit": "in",
      "appliesTo": "Beam face"
    },
    {
      "label": "5\" DIA.",
      "value": "5",
      "unit": "in",
      "appliesTo": ""
    }
  ],
  "notes": [
    "DIAPHRAGM BAR SHALL BE A 1\" DIAMETER PLAIN BAR, THREADED 5\" ON EACH END, WITH 1/4\" X 3/2\" DIAMETER WASHERS AND HEX NUTS (ASTM A 709 GRADE 36).",
    "TIGHTEN DIAPHRAGM BAR AS PER SUB-SECTION 507.3.05.C OF THE GEORGIA DOT SPECIFICATIONS.",
    "AFTER EXCESS DIAPHRAGM BAR HAS BEEN CUT OFF, PAINT DIAPHRAGM BAR, WASHER, AND NUT EXPOSED IN RECESS WITH SPECIAL PROTECTIVE COATING NO.2 P AS PER SECTION 535 OF THE GEORGIA DOT SPECIFICATIONS. AFTER PAINTING, FILL THE RECESS WITH AN APPROVED EPOXY GROUT.",
    "GALVANIZING OF THE DIAPHRAGM BAR AS PER SUB-SECTION 865.2.01.B.12 OF THE GEORGIA DOT SPECIFICATIONS IS NOT REQUIRED.",
    "RECESS DETAIL FOR DIAPHRAGM BAR ENDS"
  ],
  "labels": [
    "RECESS DETAIL FOR DIAPHRAGM BAR ENDS"
  ],
  "description": "Detail of the diaphragm bar end recess showing a 2 inch diameter hole, a 1 inch diameter diaphragm bar with threaded ends, a bolt and nut/washer assembly, and a note to cut off excess bar 1 inch from the beam face with specified coating and epoxy fill."
}
