nut

1 page · 1 crop · ×2

⚠ No class in the bridge ontology fits this itemAdd a class

The ontology would need a structural nut class.

Every dimension read for it4

  • 1" in1" CL.not attributedp11 · p11_r04
  • 3" in3"not attributedp11 · p11_r04
  • 4" in4" EACH WAYnot attributedp11 · p11_r04
  • 5" in5" DIAnot attributedp11 · p11_r04

Notes on the sheets that carry it

  • p11DIAPHRAGM BAR SHALL BE A 1" DIAMETER PLAIN BAR, THREADED 5" ON EACH END, WITH ¼" X 3/2" DIAMETER WASHERS AND HEX NUTS (ASTM A 709 GRADE 36).
  • p11TIGHTEN DIAPHRAGM BAR AS PER SUB-SECTION 507.3.05.C OF THE GEORGIA DOT SPECIFICATIONS.
  • p11AFTER EXCESS DIAPHRAGM BAR HAS BEEN CUT OFF, PAINT DIAPHRAGM BAR, WASHER, AND NUT EXPOSED IN RECESS WITH SPECIAL PROTECTIVE COATING NO. 2 P AS PER SECTION 535 OF THE GEORGIA DOT SPECIFICATIONS. AFTER PAINTING, FILL THE RECESS WITH AN APPROVED EPOXY GROUT.
  • p11GALVANIZING OF THE DIAPHRAGM BAR AS PER SUB-SECTION 865.2.01.B.12 OF THE GEORGIA DOT SPECIFICATIONS IS NOT REQUIRED.

Every crop it was read in — the drawing beside what the model took off it

Page 11

crop

p11_r04

page 11 · other_p11_r04
Original
p11_r04
{
  "view": "Detail",
  "objects": [
    {
      "name": "diaphragm bar",
      "tag": "",
      "shape": "circular",
      "material": "steel",
      "count": 1,
      "note": "1\" DIAMETER PLAIN BAR; THREADED ENDS"
    },
    {
      "name": "washer",
      "tag": "",
      "shape": "circular",
      "material": "metal",
      "count": 2,
      "note": "1/4\" X 3/2\" DIAMETER WASHERS"
    },
    {
      "name": "nut",
      "tag": "",
      "shape": "hexagonal",
      "material": "steel",
      "count": 2,
      "note": "HEX NUTS (ASTM A 709 GRADE 36)"
    },
    {
      "name": "hole",
      "tag": "",
      "shape": "circular",
      "material": "",
      "count": 1,
      "note": "2\" DIAMETER HOLE"
    }
  ],
  "measurements": [
    {
      "label": "1\" CL.",
      "value": "1\"",
      "unit": "in",
      "appliesTo": ""
    },
    {
      "label": "3\"",
      "value": "3\"",
      "unit": "in",
      "appliesTo": ""
    },
    {
      "label": "4\" EACH WAY",
      "value": "4\"",
      "unit": "in",
      "appliesTo": ""
    },
    {
      "label": "5\" DIA",
      "value": "5\"",
      "unit": "in",
      "appliesTo": ""
    },
    {
      "label": "2\" DIAMETER HOLE",
      "value": "2\"",
      "unit": "in",
      "appliesTo": "hole"
    }
  ],
  "notes": [
    "DIAPHRAGM BAR SHALL BE A 1\" DIAMETER PLAIN BAR, THREADED 5\" ON EACH END, WITH ¼\" X 3/2\" DIAMETER WASHERS AND HEX NUTS (ASTM A 709 GRADE 36).",
    "TIGHTEN DIAPHRAGM BAR AS PER SUB-SECTION 507.3.05.C OF THE GEORGIA DOT SPECIFICATIONS.",
    "AFTER EXCESS DIAPHRAGM BAR HAS BEEN CUT OFF, PAINT DIAPHRAGM BAR, WASHER, AND NUT EXPOSED IN RECESS WITH SPECIAL PROTECTIVE COATING NO. 2 P AS PER SECTION 535 OF THE GEORGIA DOT SPECIFICATIONS. AFTER PAINTING, FILL THE RECESS WITH AN APPROVED EPOXY GROUT.",
    "GALVANIZING OF THE DIAPHRAGM BAR AS PER SUB-SECTION 865.2.01.B.12 OF THE GEORGIA DOT SPECIFICATIONS IS NOT REQUIRED."
  ],
  "labels": [
    "RECESS DETAIL FOR DIAPHRAGM BAR ENDS"
  ],
  "description": "Detail view showing the recess for diaphragm bar ends with a 1\" diameter diaphragm bar, threaded ends, washers and nuts, and a 2\" diameter hole. Includes notes on material, coating, and installation requirements for the end details."
}

p11_r04Detail

  • nut×2hexagonalsteelHEX NUTS (ASTM A 709 GRADE 36)

1" in 1" CL.3" in 3"4" in 4" EACH WAY5" in 5" DIA2" in 2" DIAMETER HOLE
