Matched toRectangular Pier Shaftbridge.substructure.pier_system.pier_shaft.rectangularon “COLUMN”
| The class asks for | Value | How | From |
|---|---|---|---|
| LengthLwants m/mm | not establishedThe readings state a column width and vertical height, but do not establish a separate column length dimension. The 4'-8" dimensions are not explicitly identified as a column length. | not found | |
| WidthWwants m/mm | 2'-0" ft-inExplicitly labeled "Column width" and applies to COLUMN 2. | read | p15 · p15_r02 title block |
| HeightHwants m/mm | 9'-6" ft-inThe 9'-6" dimension is explicitly identified as a column dimension/vertical dimension for COLUMN 1 on page 14 and COLUMN 2 on page 15. | read | p14 · p14_r02 title blockp15 · p15_r02 title block |
| Instance CountNwants count | 8 countBent 2: COLUMN 1 + COLUMN 2 + COLUMN 3 + COLUMN 4 = 4 columns. Bent 3: COLUMN 1 + COLUMN 2 + COLUMN 3 + COLUMN 4 = 4 columns. 4 + 4 = 8 columns.Bent 2 elevations show Columns 1 through 4, and the Intermediate Bent 3 detail explicitly identifies four columns, COLUMN 1 through COLUMN 4. These are distinct bent details. | derived | p14 · p14_r02 title blockp14 · p14_r03 title blockp15 · p15_r02 title block |
| Concrete Gradefck | not establishedColumns are identified as reinforced concrete in the readings, but no concrete strength class or grade is stated. | not found |
Worked out by openai/gpt-5.6-terra-pro from the readings below, which are the source. A derived value shows its arithmetic — check it against the drawing before it is priced.
How the sheets named it
Every dimension read for it67
- 6'-0"minimum horizontal distance from B.F.P.R. reference to wall referencenot attributedp13 · p13_r05 2 0 min
- 2"clear cover, 3 sidesp13 · p13_r06
- 14-620 AT 6" MAX.bar quantity and maximum spacingp14 · p14_r02 title block
- 14-621 AT 6" MAX.bar quantity and maximum spacingp14 · p14_r02 title block
- 4'-8"dimensionp14 · p14_r02 title block
- 1'-3"dimensionp14 · p14_r02 title block
- 12-521bar quantityp14 · p14_r02 title block
- 3½"dimensionp14 · p14_r02 title block
- 8'-9"dimensionp14 · p14_r02 title block
- 14-522 DBLbar quantityp14 · p14_r02 title block
- 2"dimensionp14 · p14_r02 title block
- 9-620 AT 12" MAX.bar quantity and maximum spacingp14 · p14_r02 title block
- 9-621 AT 12" MAX.bar quantity and maximum spacingp14 · p14_r02 title block
- 9-620 AT 6" MAX.bar quantity and maximum spacingp14 · p14_r02 title block
- 9-621 AT 6" MAX.bar quantity and maximum spacingp14 · p14_r02 title block
- 7-620 AT 12" MAX.bar quantity and maximum spacingp14 · p14_r02 title block
- 7-621 AT 12" MAX.bar quantity and maximum spacingp14 · p14_r02 title block
- 14-620 AT 6" MAX.bar quantity and maximum spacingp14 · p14_r02 title block
- 14-621 AT 6" MAX.bar quantity and maximum spacingp14 · p14_r02 title block
- 9'-6"column dimensionp14 · p14_r02 title block
- 3½"cover/offsetp14 · p14_r03 title block
- 2"offsetp14 · p14_r03 title block
- 8"offsetp14 · p14_r03 title block
- 8"offsetp14 · p14_r03 title block
- 2"offsetp14 · p14_r03 title block
- 3½"cover/offsetp14 · p14_r03 title block
- 9"vertical dimensionp14 · p14_r02
- 4'-8"vertical dimensionp14 · p14_r02
- 8'-9"cap/column horizontal dimensionp14 · p14_r02
- 8'-9"cap/column horizontal dimensionp14 · p14_r02
- 3½"horizontal dimensionp14 · p14_r02
- 2"horizontal dimensionp14 · p14_r02
- 8"horizontal dimensionp14 · p14_r02
- 3½"horizontal dimensionp14 · p14_r02
- 2"horizontal dimensionp14 · p14_r02
- 8"horizontal dimensionp14 · p14_r02
- 1'-0"horizontal dimensionp14 · p14_r02
- 2'-0"vertical dimensionp14 · p14_r02
- 1'-0"vertical dimensionp14 · p14_r02
- 9'-6"column height dimensionp14 · p14_r02
- EL. 181.25elevationp14 · p14_r02
- EL. 181.11elevationp14 · p14_r02
- EL. 181.32elevationp14 · p14_r02
- EL. 181.73elevationp14 · p14_r02
- EL. 181.80elevationp14 · p14_r02
- 2"horizontal dimensionp14 · p14_r03
- 8"horizontal dimensionp14 · p14_r03
- 12-131 SERIESColumn reinforcingp15 · p15_r02 title block
- 2'-0"Column widthp15 · p15_r02 title block
- 9'-6"Column vertical dimensionp15 · p15_r02 title block
- 1'-0"Column top and bottom offsetsp15 · p15_r02 title block
- 12-I131 SERIESBar calloutp15 · p15_r02
- 1'-0"Dimensionp15 · p15_r02
- 2'-0"Dimensionp15 · p15_r02
- 12-I130 SERIESBar calloutp15 · p15_r02
- 9'-6"Dimensionp15 · p15_r02
- 4'-8"Dimensionp15 · p15_r02
- 14-630 AT 6" MAX.Bar callout and spacingp15 · p15_r02
- 14-63I AT 6" MAX.Bar callout and spacingp15 · p15_r02
- 9-630 AT 12" MAX.Bar callout and spacingp15 · p15_r02
- 9-63I AT 6" MAX.Bar callout and spacingp15 · p15_r02
- 7-630 AT 12" MAX.Bar callout and spacingp15 · p15_r02
- 7-63I AT 12" MAX.Bar callout and spacingp15 · p15_r02
- 12-I131 SERIESBar calloutp15 · p15_r02
- 12-I130 SERIESBar calloutp15 · p15_r02
- 3/8" = 1'-0"drawing scalenot attributedp16 · p16_r08 footing plan bent 2
- 3/8" = 1'-0"Scalenot attributedp16 · p16_r08
Notes on the sheets that carry it
- p14NOTES:
- p141. SEE BRIDGE SHEET NO. 16 FOR CAP, COLUMN AND FOOTING SECTIONS.
- p142. BARS 422 NOT SHOWN.
- p143. EXTEND BARS 1121A 3'-6" INTO CAP.
- p14MECHANICAL COUPLER, TYP. SEE SPECIAL PROVISION 511
- p14* REQUIRED CONSTRUCTION JOINT. AT CONTRACTOR'S OPTION, CONSTRUCTION JOINT MAY BE RELOCATED TO TOP OF FOOTING.
- p14PILES ARE DESIGNED FOR A MAXIMUM FACTORED AXIAL LOAD OF 237 KIPS.
- p14"I6 FOR CAP, SECTIONS." (partial text at left crop edge)
- p14"-6” INTO CAP." (partial text at left crop edge)
- p14", TYP." (partial text at lower-left crop edge)
- p14"ER HOLES" (partial text at lower-left crop edge)
- p141. SEE BRIDGE SHEET NO.16 FOR CAP, COLUMN AND FOOTING REINFORCEMENT AND FOOTING NOTES.
- p1444-#21 AT EQ. SPS.
- p1411 SPS. AT 7"
- p1412-#21 SERIES
- p146 SPS AT 5"
- p1414-#22 DBL
- p1425-#21 AT EQ. SPS.
- p14EL. 151.00, TYP.
- p152. BARS 432 NOT SHOWN.
- p153. EXTEND BARS 131A 3'-9" INTO CAP.
- p15* REQUIRED CONSTRUCTION JOINT. AS CONTRACTOR'S OPTION, CONSTRUCTION JOINT MAY BE RELOCATED TO TOP OF FOOTING.
- p15MECHANICAL COUPLER, TYP. SEE SPECIAL PROVISION.
- p15PILES ARE DESIGNED FOR A MAXIMUM FACTORED AXIAL LOAD OF 222 KIPS.
- p151. SEE BRIDGE SHEET NO. 16 FOR CAP, COLUMN AND FOOTING DETAILS.
- p15MECHANICAL COUPLER, TYP. SEE SPECIAL PROVISION 51.
- p15* CONST. JT., TYP.
- p15PILES ARE DESIGNED FOR A MAXIMUM FACTORED AXIAL LOAD OF 220 KIPS.
- p15ALL PILES SHALL BE STEEL H-PILES HP 12 X 53. partial
- p162" MIN. CL., TYP.
- p162" CL., 3 SIDES
- p165-422 OR 5-432 EACH FACE
- p172" MIN. CL.
- p171'-0" TYP.
Every crop it was read in — the drawing beside what the model took off it
Page 13
p13_r05 2 0 minDetail
- vertical support members×2paired parallel-line vertical membersExtend below crop with break symbols.
6'-0" minimum horizontal distance from B.F.P.R. reference to wall reference3'-0" horizontal cap dimension2'-0" minimum vertical cap dimension
p13_r06Section
- vertical member×1rectangularContinues below the section; lower extent is outside the crop.
3'-0" overall width1'-6" half width1'-6" half width2" minimum clear cover1'-0" typical vertical spacing2'-0" minimum depth2" clear cover, 3 sides1'-6" half width+2 more
Page 14
p14_r02 title blockElevation
- columnCOLUMN 1×1rectangularVertical column beneath cap.
- columnCOLUMN 2×1rectangularVertical column beneath cap.
44-421 cap reinforcement spacingAT EQ. SPS. cap reinforcement spacingEL. 185.78 elevationEL. 185.23 elevationEL. 185.96 elevationEL. 185.41 elevationEL. 186.10 elevationEL. 185.55 elevation+63 more
p14_r03 title blockElevation
- columnCOLUMN 3×1rectangularreinforced concreteShown supported on a footing.
- columnCOLUMN 4×1rectangularreinforced concreteShown supported on a footing.
44-#21 AT EQ. SPS. reinforcement spacing and quantityEL. 186.42 elevationEL. 185.84 elevationEL. 186.29 elevationEL. 185.75 elevationEL. 186.12 elevationEL. 185.58 elevationEL. 185.94 elevation+37 more
p14_r02Elevation
- column℄ COLUMN 1×1rectangularVertical column below cap.
- column℄ COLUMN 2×1rectangularVertical column below cap.
44-421 cap reinforcement spacing4'-10" minimum cap depth9" vertical dimension4'-8" vertical dimension8'-9" cap/column horizontal dimension25'-0" cap/column horizontal dimension8'-9" cap/column horizontal dimension6" bar spacing+61 more
p14_r03Elevation
- columnCOLUMN 3×1rectangularLower portion is broken in elevation.
- columnCOLUMN 4×1rectangularLower portion is broken in elevation.
44-#21 cap reinforcement spacing4'-0" cap depthMIN. minimum cap depthEL. 186.42 elevation (BK)EL. 185.84 elevation (AH)EL. 186.29 elevation (BK)EL. 185.75 elevation (AH)EL. 186.12 elevation (BK)+30 more
Page 15
p15_r02 title blockUnclear
- ColumnCOLUMN 1, COLUMN 2, COLUMN 3, COLUMN 4×4rectangularCenterlines are indicated.
44-431 AT EQ. SPS. Cap reinforcing8-1132 Cap reinforcing2-530 Cap reinforcing8-1133 Cap reinforcing4'-0" MIN. Cap depth25'-0" Cap length between indicated column regions8'-9" End dimension12-531 Column reinforcing+65 more
p15_r02Detail
- ColumnCOLUMN 1×1rectangularreinforced concrete
- ColumnCOLUMN 2×1rectangularreinforced concrete
- ColumnCOLUMN 3×1rectangularreinforced concrete
- ColumnCOLUMN 4×1rectangularreinforced concrete
44-43I AT EQ. SPS. Cap reinforcing-bar spacingEL. 185.79 (AH) ElevationEL. 185.24 (BK) ElevationEL. 185.98 (AH) ElevationEL. 185.43 (BK) ElevationEL. 186.14 (AH) ElevationEL. 185.60 (BK) ElevationEL. 186.30 (AH) Elevation+84 more
Page 16
p16_r02 footing plan bent 3Detail
- column℄ COLUMNrectangularOnly the column centerline/location is shown in the footing plan; a column projection is shown in Section B-B.
4'-3" overall width at ℄ BENT2'-1½" width from ℄ BENT2'-1½" width from ℄ BENT11½" spacing1'-2" spacing1'-2" spacing11½" spacing2" minimum clear cover+14 more
p16_r08 footing plan bent 2Plan
- column×1Indicated by a vertical dashed centerline labeled CL COLUMN.
11'-6" overall footing width1'-3" horizontal end spacing4'-6" horizontal pile spacing4'-6" horizontal pile spacing1'-3" horizontal end spacing11'-6" overall footing length1'-3" vertical end spacing4'-6" vertical pile spacing+3 more
p16_r08Plan
- Column×1Shown by intersecting dashed centerlines at footing center.
11'-6" Overall footing width1'-3" Footing width segment4'-6" Pile spacing4'-6" Pile spacing1'-3" Footing width segment11'-6" Overall footing length1'-3" Footing length segment4'-6" Pile spacing+3 more
Page 17
p17_r05 2 0 minDetail
- vertical support members×2rectangularShown extending below the cap; lower portions are broken off.
6'-0" MIN. minimum horizontal distance from B.F.P.R. to wall reference line3'-0" horizontal cap dimension2'-0" MIN. minimum vertical cap dimension
p17_r06Section
- vertical member×1rectangularOnly the portion passing through the reinforced concrete member is visible.
3'-0" overall width1'-6" half width1'-6" half width2" MIN. minimum clear cover2'-0" MIN. minimum height1'-0" typical dimension2" clear cover, 3 sides1'-6" half width+2 more
