Drawing → BOQ
← Mindmapwhat the drawings said

Silicone Sealant

2 pages · 4 crops · ×7 · material

⚠ No class in the bridge ontology fits this itemAdd a class

The ontology would need a silicone joint sealant material class.

How the sheets named it

Silicone adhesivesilicone adhesivejoint sealer

Every dimension read for it3

  • 1/4″ Rradiusnot attributedp4 · p04_r03
  • 1/4"joint recess depthp9 · p09_r05
  • 1/2"joint recess widthp9 · p09_r05

Notes on the sheets that carry it

  • p4* PREFORMED SILICONE JOINT SEAL AS PER SPECIAL PROVISION SECTION 449
  • p4FILLER MATERIAL IN ACCORDANCE WITH SUB-SECTION 833.2.01 OF THE GEORGIA DOT SPECIFICATIONS, HOLD IN PLACE WITH 10d GALV. NAILS
  • p9SLAB REINFORCEMENT NOT SHOWN
  • p9SILICONE SEALANT
  • p9TYPE JOINT SEALER
  • p9(TYPE B, C OR D)
  • p9ROUND TO 1/4" R
  • p9REQUIRED CONST. JOINT., TYP.
  • p9SILICONE SEALANT TYPE JOINT SEALER (TYPE B, C OR D)

Every crop it was read in — the drawing beside what the model took off it

Page 4

crop

p04_r03 expansion joint details

page 4 · gdot_drawing_83a3db2262b94086918a1e232d2b9607_p04_r03_expansion_joint_details
Original
p04_r03 expansion joint details
{
  "view": "Detail",
  "objects": [
    {
      "name": "Preformed silicone joint seal",
      "tag": "*",
      "shape": "profiled",
      "material": "silicone",
      "count": 1,
      "note": "Installed in the joint opening."
    },
    {
      "name": "Silicone adhesive",
      "tag": "",
      "shape": "irregular side strips",
      "material": "silicone",
      "count": 2,
      "note": "Shown on both sides of the joint seal."
    },
    {
      "name": "Filler material",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 1,
      "note": "Hatched material below the joint seal."
    }
  ],
  "measurements": [
    {
      "label": "Joint opening width",
      "value": "1 3/8″",
      "unit": "in.",
      "appliesTo": "Preformed silicone joint seal"
    },
    {
      "label": "Vertical dimension",
      "value": "1/2″",
      "unit": "in.",
      "appliesTo": "Joint detail"
    },
    {
      "label": "Radius",
      "value": "1/4″ R",
      "unit": "in.",
      "appliesTo": "Joint edge"
    }
  ],
  "notes": [
    "* PREFORMED SILICONE JOINT SEAL AS PER SPECIAL PROVISION SECTION 449",
    "FILLER MATERIAL IN ACCORDANCE WITH SUB-SECTION 833.2.01 OF THE GEORGIA DOT SPECIFICATIONS, HOLD IN PLACE WITH 10d GALV. NAILS"
  ],
  "labels": [
    "XPANSION JOINT DETAILS",
    "END BENTS 1 AND 4"
  ],
  "description": "This crop shows a cross-sectional expansion-joint detail between two adjacent vertical joint faces. It documents a preformed silicone joint seal with silicone adhesive and filler material beneath the seal; the title and lower applicability label are partially cropped."
}

p04_r03 expansion joint detailsDetail

  • Silicone adhesive×2irregular side stripssiliconeShown on both sides of the joint seal.

1 3/8″ in. Joint opening width1/2″ in. Vertical dimension1/4″ R in. Radius

crop

p04_r03

page 4 · other_p04_r03
Original
p04_r03
{
  "view": "Detail",
  "objects": [
    {
      "name": "preformed silicone joint seal",
      "tag": "*",
      "shape": "profiled extruded seal",
      "material": "silicone",
      "count": 1,
      "note": "Installed within the expansion joint opening."
    },
    {
      "name": "silicone adhesive",
      "tag": "",
      "shape": "",
      "material": "silicone",
      "count": 2,
      "note": "Shown at both sides of the joint seal."
    },
    {
      "name": "filler material",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 1,
      "note": "Shown below the joint seal."
    }
  ],
  "measurements": [
    {
      "label": "joint opening width",
      "value": "1 3/8″",
      "unit": "",
      "appliesTo": "preformed silicone joint seal"
    },
    {
      "label": "vertical dimension",
      "value": "1/2″",
      "unit": "",
      "appliesTo": "preformed silicone joint seal"
    },
    {
      "label": "radius",
      "value": "1/4″ R",
      "unit": "",
      "appliesTo": ""
    }
  ],
  "notes": [
    "* PREFORMED SILICONE JOINT SEAL AS PER SPECIAL PROVISION SECTION 449",
    "FILLER MATERIAL IN ACCORDANCE WITH SUB-SECTION 833.2.01 OF THE GEORGIA DOT SPECIFICATIONS, HOLD IN PLACE WITH 10d GALV. NAILS"
  ],
  "labels": [
    "EXPANSION JOINT DETAILS",
    "END BENTS 1 AND 4"
  ],
  "description": "This crop shows an expansion joint detail for End Bents 1 and 4. It depicts a preformed silicone joint seal adhered at both sides over filler material held in place with galvanized nails."
}

p04_r03Detail

  • silicone adhesive×2siliconeShown at both sides of the joint seal.

1 3/8″ joint opening width1/2″ vertical dimension1/4″ R radius

Page 9

crop

p09_r05 detail a

page 9 · gdot_drawing_83a3db2262b94086918a1e232d2b9607_p09_r05_detail_a
Original
p09_r05 detail a
{
  "view": "Detail",
  "objects": [
    {
      "name": "slab",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 2,
      "note": "Slab reinforcement not shown."
    },
    {
      "name": "construction joint",
      "tag": "",
      "shape": "keyed joint",
      "material": "",
      "count": 1,
      "note": "Required construction joint, typical."
    },
    {
      "name": "silicone sealant",
      "tag": "",
      "shape": "",
      "material": "silicone",
      "count": 1,
      "note": ""
    },
    {
      "name": "joint sealer",
      "tag": "",
      "shape": "",
      "material": "",
      "count": 1,
      "note": "Type B, C or D."
    }
  ],
  "measurements": [
    {
      "label": "",
      "value": "1/4\"",
      "unit": "",
      "appliesTo": "joint detail"
    },
    {
      "label": "",
      "value": "1/2\"",
      "unit": "",
      "appliesTo": "joint detail"
    },
    {
      "label": "",
      "value": "3/4\"",
      "unit": "",
      "appliesTo": "construction joint"
    },
    {
      "label": "ROUND TO",
      "value": "1/4\" R",
      "unit": "",
      "appliesTo": "construction joint"
    },
    {
      "label": "SCALE",
      "value": "3/4\" = 1'-0\"",
      "unit": "",
      "appliesTo": "SECTION THRU DIAPHRAGM SPAN 2"
    }
  ],
  "notes": [
    "SLAB REINFORCEMENT NOT SHOWN",
    "SILICONE SEALANT",
    "TYPE JOINT SEALER",
    "(TYPE B, C OR D)",
    "ROUND TO 1/4\" R",
    "REQUIRED CONST. JOINT., TYP."
  ],
  "labels": [
    "SECTION THRU DIAPHRAGM",
    "SPAN 2",
    "SCALE: 3/4\" = 1'-0\"",
    "DETAIL \"A\"",
    "NO SCALE"
  ],
  "description": "This crop shows Detail \"A\", a sectional detail through the Span 2 diaphragm. It depicts a required typical construction joint between slab portions, with silicone sealant, type joint sealer, and a rounded joint edge."
}

p09_r05 detail aDetail

  • silicone sealant×1silicone
  • joint sealer×1Type B, C or D.

1/4"1/2"3/4"1/4" R ROUND TO3/4" = 1'-0" SCALE

crop

p09_r05

page 9 · other_p09_r05
Original
p09_r05
{
  "view": "Detail",
  "objects": [
    {
      "name": "slab",
      "tag": "",
      "shape": "rectangular section with recessed joint edge",
      "material": "",
      "count": 2,
      "note": "Slab reinforcement not shown."
    },
    {
      "name": "construction joint",
      "tag": "",
      "shape": "vertical joint",
      "material": "",
      "count": 1,
      "note": "Required construction joint, typical."
    },
    {
      "name": "silicone sealant",
      "tag": "",
      "shape": "recessed joint seal",
      "material": "silicone",
      "count": 1,
      "note": "Type joint sealer (Type B, C or D)."
    }
  ],
  "measurements": [
    {
      "label": "joint recess depth",
      "value": "1/4\"",
      "unit": "",
      "appliesTo": "silicone sealant"
    },
    {
      "label": "joint recess width",
      "value": "1/2\"",
      "unit": "",
      "appliesTo": "silicone sealant"
    },
    {
      "label": "joint width",
      "value": "3/4\"",
      "unit": "",
      "appliesTo": "construction joint"
    },
    {
      "label": "round",
      "value": "1/4\" R",
      "unit": "",
      "appliesTo": "construction joint"
    },
    {
      "label": "scale",
      "value": "3/4\" = 1'-0\"",
      "unit": "",
      "appliesTo": "SECTION THRU DIAPHRAGM"
    }
  ],
  "notes": [
    "SLAB REINFORCEMENT NOT SHOWN",
    "SILICONE SEALANT TYPE JOINT SEALER (TYPE B, C OR D)",
    "ROUND TO 1/4\" R",
    "REQUIRED CONST. JOINT., TYP."
  ],
  "labels": [
    "SECTION THRU DIAPHRAGM",
    "SPAN 2",
    "DETAIL \"A\"",
    "NO SCALE"
  ],
  "description": "This crop shows Detail \"A\", a section through the diaphragm at Span 2. It documents a typical required construction joint between slab portions, including a recessed silicone sealant joint configuration."
}

p09_r05Detail

  • silicone sealant×1recessed joint sealsiliconeType joint sealer (Type B, C or D).

1/4" joint recess depth1/2" joint recess width3/4" joint width1/4" R round3/4" = 1'-0" scale
