Slot

{
  "view": "Notes",
  "objects": [
    {
      "name": "smooth dowel",
      "tag": "",
      "shape": "circular",
      "material": "",
      "count": null,
      "note": "Located at fixed and expansion ends as noted."
    },
    {
      "name": "hole",
      "tag": "",
      "shape": "circular",
      "material": "",
      "count": null,
      "note": "At fixed ends."
    },
    {
      "name": "slot",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": null,
      "note": "At expansion ends."
    }
  ],
  "measurements": [
    {
      "label": "hole diameter",
      "value": "1 3/4\"",
      "unit": "",
      "appliesTo": "hole"
    },
    {
      "label": "hole depth",
      "value": "7\"",
      "unit": "",
      "appliesTo": "hole"
    },
    {
      "label": "slot width",
      "value": "4\"",
      "unit": "",
      "appliesTo": "slot"
    },
    {
      "label": "slot dimension",
      "value": "1 3/4\"",
      "unit": "",
      "appliesTo": "slot"
    },
    {
      "label": "slot depth",
      "value": "7\"",
      "unit": "",
      "appliesTo": "slot"
    },
    {
      "label": "smooth dowel diameter",
      "value": "1 1/2\"",
      "unit": "",
      "appliesTo": "smooth dowel"
    }
  ],
  "notes": [
    "4. AT ℄ BEARING, FORM A 1 3/4\" DIAMETER X 7\" DEEP HOLE AT THE FIXED ENDS AND A 4\" X 1 3/4\" X 7\" DEEP SLOT AT THE EXPANSION ENDS FOR A 1 1/2\" DIAMETER SMOOTH DOWEL. SEE PLAN AND ELEVATION SHEET FOR LOCATION OF FIXED AND EXPANSION ENDS."
  ],
  "labels": [],
  "description": "This crop contains note 4 concerning dowel holes and slots at bearing locations. It specifies a circular hole at fixed ends and a rectangular slot at expansion ends for a smooth dowel; the plan and elevation sheet is referenced for end locations."
}
