GDOT20

{
  "view": "Cross Section",
  "objects": [
    {
      "name": "Rectangular member",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 1,
      "note": "Outlined rectangular section; material is not stated in this crop."
    },
    {
      "name": "Reinforcement bars",
      "tag": "443A",
      "shape": "circular bar ends as drawn",
      "material": "",
      "count": 10,
      "note": "5-443A E.A. FACE AT EQ. SPS."
    },
    {
      "name": "Reinforcement bars",
      "tag": "443B",
      "shape": "circular bar ends as drawn",
      "material": "",
      "count": 6,
      "note": "3-443B E.A. FACE AT EQ. SPS."
    },
    {
      "name": "Reinforcement",
      "tag": "540B",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Callout leaders point to reinforcement near the transition between 443A and 443B bar groups."
    }
  ],
  "measurements": [
    {
      "label": "Section width",
      "value": "1'-0\"",
      "unit": "",
      "appliesTo": "Rectangular member"
    },
    {
      "label": "443A reinforcement quantity",
      "value": "5",
      "unit": "",
      "appliesTo": "443A"
    },
    {
      "label": "443B reinforcement quantity",
      "value": "3",
      "unit": "",
      "appliesTo": "443B"
    }
  ],
  "notes": [
    "5-443A E.A. FACE AT EQ. SPS.",
    "3-443B E.A. FACE AT EQ. SPS."
  ],
  "labels": [
    "SECTION F-F"
  ],
  "description": "This crop shows SECTION F-F, a narrow rectangular cross section with two vertical rows of reinforcement bar ends. The section is dimensioned 1'-0\" wide and includes 443A and 443B reinforcement called out at each face at equal spacing, plus a 540B reinforcement callout."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "reinforcement bars",
      "tag": "540A",
      "shape": "straight",
      "material": "reinforcement steel",
      "count": 5,
      "note": "Vertical bar layout indicated in the upper portion of the detail."
    },
    {
      "name": "reinforcement bars",
      "tag": "540B",
      "shape": "straight",
      "material": "reinforcement steel",
      "count": 4,
      "note": "Vertical bar layout indicated in the upper-right portion of the detail."
    },
    {
      "name": "reinforcement bars",
      "tag": "443A",
      "shape": "straight",
      "material": "reinforcement steel",
      "count": 5,
      "note": "Horizontal bar layout indicated along the right side of the detail."
    },
    {
      "name": "reinforcement bars",
      "tag": "443B",
      "shape": "straight",
      "material": "reinforcement steel",
      "count": 3,
      "note": "Horizontal bar layout indicated in the lower-right portion of the detail."
    }
  ],
  "measurements": [
    {
      "label": "overall horizontal dimension",
      "value": "5'-4¾\"",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "reinforcement bar quantity",
      "value": "5",
      "unit": "",
      "appliesTo": "540A"
    },
    {
      "label": "reinforcement bar quantity",
      "value": "4",
      "unit": "",
      "appliesTo": "540B"
    },
    {
      "label": "reinforcement bar quantity",
      "value": "5",
      "unit": "",
      "appliesTo": "443A"
    },
    {
      "label": "reinforcement bar quantity",
      "value": "3",
      "unit": "",
      "appliesTo": "443B"
    }
  ],
  "notes": [],
  "labels": [
    "DETAIL 4",
    "F",
    "F"
  ],
  "description": "This crop shows Detail 4, a reinforcement layout within a heavy outlined rectangular area with an internal stepped/re-entrant outline. Reinforcing bars are identified by marks 540A, 540B, 443A, and 443B, and section/detail references F are shown at the bottom."
}

{
  "view": "Title Block",
  "objects": [],
  "measurements": [
    {
      "label": "Scale",
      "value": "3/4” = 1'-0”",
      "unit": "",
      "appliesTo": "Sheet"
    },
    {
      "label": "Print scale check",
      "value": "1 INCH",
      "unit": "",
      "appliesTo": "WHEN PRINTED FULL SIZE"
    }
  ],
  "notes": [
    "(UNLESS OTHERWISE NOTED)"
  ],
  "labels": [
    "BENT 4",
    "NO SCALE",
    "BRIDGE NO. LT. AND RT.",
    "S&A Atlanta",
    "SASTRY & ASSOCIATES, INC.",
    "11030 JONES BRIDGE ROAD, SUITE 201",
    "ALPHARETTA, GA 30022",
    "PHONE: 678-366-9375",
    "FAX: 770-442-0761",
    "GEORGIA",
    "DEPARTMENT OF TRANSPORTATION",
    "ENGINEERING DIVISION-OFFICE OF BRIDGES AND STRUCTURES",
    "INTERMEDIATE BENT DETAILS",
    "SR 21 @ NS #620272Y",
    "JENKINS COUNTY",
    "0019181",
    "DRAWING NO.",
    "35-0016",
    "BRIDGE SHEET",
    "16 OF 21",
    "DATE",
    "REVISIONS",
    "BY",
    "SCALE: 3/4” = 1'-0”",
    "MAY 2025",
    "DESIGNED",
    "UP",
    "DRAWN",
    "EPR",
    "CHECKED",
    "AS",
    "DESIGN GROUP",
    "JBK",
    "REVIEWED",
    "DLC/SKG",
    "APPROVED",
    "DPD",
    "0019181_0016.dgn",
    "No.19371",
    "PROFESSIONAL",
    "ARUNNA SASTRY",
    "1 INCH WHEN PRINTED FULL SIZE"
  ],
  "description": "This crop shows the sheet title block for Bridge Sheet 16 of 21, Drawing No. 35-0016. The sheet is titled “INTERMEDIATE BENT DETAILS” for SR 21 @ NS #620272Y in Jenkins County, Georgia; no construction detail geometry is shown in this crop."
}

{
  "view": "Section",
  "objects": [
    {
      "name": "concrete member",
      "tag": "",
      "shape": "square",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Reinforcement section shown; member name is not visible in this crop."
    },
    {
      "name": "longitudinal reinforcement bars",
      "tag": "12-1121 OR 1131",
      "shape": "circular in section",
      "material": "",
      "count": 12,
      "note": "Twelve filled circular bar locations are shown around the perimeter."
    },
    {
      "name": "perimeter reinforcement tie",
      "tag": "620 OR 630",
      "shape": "rectangular with hooked end",
      "material": "",
      "count": null,
      "note": "Callout points to the perimeter tie at the right side."
    },
    {
      "name": "diagonal reinforcement tie legs",
      "tag": "621 OR 631",
      "shape": "diagonal",
      "material": "",
      "count": null,
      "note": "Callout points to a diagonal tie leg."
    }
  ],
  "measurements": [
    {
      "label": "section width",
      "value": "3'-6\"",
      "unit": "",
      "appliesTo": "concrete member"
    },
    {
      "label": "section height",
      "value": "3'-6\"",
      "unit": "",
      "appliesTo": "concrete member"
    },
    {
      "label": "CL. ALL SIDES",
      "value": "2\"",
      "unit": "",
      "appliesTo": "reinforcement"
    }
  ],
  "notes": [
    "2\" CL. ALL SIDES"
  ],
  "labels": [
    "SECTION C-C"
  ],
  "description": "This crop shows Section C-C through a square reinforced-concrete member. The section is 3'-6\" by 3'-6\" and depicts twelve perimeter longitudinal bars with perimeter and diagonal reinforcement ties."
}

{
  "view": "Section",
  "objects": [
    {
      "name": "reinforced concrete bent member",
      "tag": "",
      "shape": "stepped rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Sectioned member shown about C/L BENT with bearing centerlines indicated."
    },
    {
      "name": "reinforcement bars",
      "tag": "2-520 OR 2-530",
      "shape": "circular bar sections",
      "material": "steel",
      "count": 2,
      "note": "Two upper reinforcing bars are shown."
    },
    {
      "name": "reinforcement bars",
      "tag": "8-1121 OR 8-1131",
      "shape": "circular bar sections",
      "material": "steel",
      "count": 8,
      "note": "Eight reinforcing bars are shown along the upper level."
    },
    {
      "name": "reinforcement bars",
      "tag": "5-422 OR 5-432",
      "shape": "circular bar sections",
      "material": "steel",
      "count": 10,
      "note": "Callout states EACH FACE; five bar sections are visible at each side face."
    },
    {
      "name": "reinforcement",
      "tag": "44-421 OR 44-431",
      "shape": "rectangular/linear",
      "material": "steel",
      "count": null,
      "note": "Leader points to reinforcement at the right side of the member."
    },
    {
      "name": "reinforcement",
      "tag": "52I OR 53I",
      "shape": "linear",
      "material": "steel",
      "count": null,
      "note": "Leader points to vertical reinforcement at the right side."
    },
    {
      "name": "reinforcement bars",
      "tag": "8-1123 OR 8-1133",
      "shape": "circular bar sections",
      "material": "steel",
      "count": 8,
      "note": "Eight reinforcing bars are shown along the bottom."
    }
  ],
  "measurements": [
    {
      "label": "Overall width",
      "value": "4'-3\"",
      "unit": "",
      "appliesTo": "reinforced concrete bent member"
    },
    {
      "label": "Width from C/L BENT to left side",
      "value": "2'-1½\"",
      "unit": "",
      "appliesTo": "reinforced concrete bent member"
    },
    {
      "label": "Width from C/L BENT to right side",
      "value": "2'-1½\"",
      "unit": "",
      "appliesTo": "reinforced concrete bent member"
    },
    {
      "label": "Left outside segment",
      "value": "11½\"",
      "unit": "",
      "appliesTo": "reinforced concrete bent member"
    },
    {
      "label": "Left intermediate segment",
      "value": "1'-2\"",
      "unit": "",
      "appliesTo": "reinforced concrete bent member"
    },
    {
      "label": "Right intermediate segment",
      "value": "1'-2\"",
      "unit": "",
      "appliesTo": "reinforced concrete bent member"
    },
    {
      "label": "Right outside segment",
      "value": "11½\"",
      "unit": "",
      "appliesTo": "reinforced concrete bent member"
    },
    {
      "label": "Minimum overall depth",
      "value": "4'-0\" MIN.",
      "unit": "",
      "appliesTo": "reinforced concrete bent member"
    },
    {
      "label": "Bottom depth",
      "value": "9\"",
      "unit": "",
      "appliesTo": "reinforced concrete bent member"
    },
    {
      "label": "Minimum clear cover, typical",
      "value": "2\"",
      "unit": "",
      "appliesTo": "reinforcement"
    },
    {
      "label": "Clear cover, 3 sides",
      "value": "2\"",
      "unit": "",
      "appliesTo": "reinforcement"
    }
  ],
  "notes": [
    "2\" MIN. CL., TYP.",
    "5-422 OR 5-432 EACH FACE",
    "2-520 OR 2-530",
    "8-1121 OR 8-1131",
    "44-421 OR 44-431",
    "2\" CL., 3 SIDES",
    "52I OR 53I",
    "8-1123 OR 8-1133"
  ],
  "labels": [
    "C/L BENT",
    "C/L BRNG.",
    "SECTION A-A"
  ],
  "description": "This crop shows SECTION A-A through a stepped reinforced-concrete bent member. It documents member geometry, bearing and bent centerlines, clear cover, and reinforcing-bar callouts at the upper, side, and bottom faces."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "bent cap",
      "tag": "",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Shown in SECTION B-B with bearing and bent centerlines."
    },
    {
      "name": "footing",
      "tag": "BENT 3",
      "shape": "rectangular",
      "material": "",
      "count": 1,
      "note": "Shown in FOOTING PLAN - BENT 3."
    },
    {
      "name": "pile",
      "tag": "",
      "shape": "H-section symbol",
      "material": "",
      "count": 6,
      "note": "Six pile symbols are visible in the footing plan."
    },
    {
      "name": "reinforcement bar",
      "tag": "520 OR 530",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Callout shown as 2-520 OR 2-530."
    },
    {
      "name": "reinforcement bar",
      "tag": "I121 OR I131",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Callout shown as 8-I121 OR 8-I131."
    },
    {
      "name": "reinforcement bar",
      "tag": "421 OR 431",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Callout shown as 44-421 OR 44-431."
    },
    {
      "name": "reinforcement bar",
      "tag": "422 OR 432",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Callout shown as 5-422 OR 5-432 EACH FACE."
    },
    {
      "name": "reinforcement bar",
      "tag": "521 OR 531",
      "shape": "",
      "material": "",
      "count": null,
      "note": ""
    },
    {
      "name": "reinforcement bar",
      "tag": "522 OR 532",
      "shape": "",
      "material": "",
      "count": null,
      "note": ""
    },
    {
      "name": "reinforcement bar",
      "tag": "I123 OR I133",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Callout shown as 8-I123 OR 8-I133."
    }
  ],
  "measurements": [
    {
      "label": "overall width at SECTION B-B",
      "value": "4'-3\"",
      "unit": "",
      "appliesTo": "bent cap"
    },
    {
      "label": "centerline-to-centerline width",
      "value": "2'-1½\"",
      "unit": "",
      "appliesTo": "bent cap"
    },
    {
      "label": "centerline-to-centerline width",
      "value": "2'-1½\"",
      "unit": "",
      "appliesTo": "bent cap"
    },
    {
      "label": "bearing offset",
      "value": "11½\"",
      "unit": "",
      "appliesTo": "bent cap"
    },
    {
      "label": "intermediate spacing",
      "value": "1'-2\"",
      "unit": "",
      "appliesTo": "bent cap"
    },
    {
      "label": "intermediate spacing",
      "value": "1'-2\"",
      "unit": "",
      "appliesTo": "bent cap"
    },
    {
      "label": "bearing offset",
      "value": "11½\"",
      "unit": "",
      "appliesTo": "bent cap"
    },
    {
      "label": "minimum depth",
      "value": "4'-0\" MIN.",
      "unit": "",
      "appliesTo": "bent cap"
    },
    {
      "label": "bottom cover/depth dimension",
      "value": "9\"",
      "unit": "",
      "appliesTo": "bent cap"
    },
    {
      "label": "reinforcement quantity",
      "value": "5-422 OR 5-432",
      "unit": "",
      "appliesTo": "bent cap"
    },
    {
      "label": "reinforcement quantity",
      "value": "2-520 OR 2-530",
      "unit": "",
      "appliesTo": "bent cap"
    },
    {
      "label": "reinforcement quantity",
      "value": "8-I121 OR 8-I131",
      "unit": "",
      "appliesTo": "bent cap"
    },
    {
      "label": "reinforcement quantity",
      "value": "44-421 OR 44-431",
      "unit": "",
      "appliesTo": "bent cap"
    },
    {
      "label": "reinforcement quantity",
      "value": "8-I123 OR 8-I133",
      "unit": "",
      "appliesTo": "bent cap"
    },
    {
      "label": "footing overall width",
      "value": "13'-0\"",
      "unit": "",
      "appliesTo": "BENT 3 footing"
    },
    {
      "label": "footing overall length",
      "value": "13'-0\"",
      "unit": "",
      "appliesTo": "BENT 3 footing"
    },
    {
      "label": "footing edge offset",
      "value": "1'-3\"",
      "unit": "",
      "appliesTo": "BENT 3 footing"
    },
    {
      "label": "pile spacing",
      "value": "5'-3\"",
      "unit": "",
      "appliesTo": "BENT 3 footing"
    },
    {
      "label": "pile spacing",
      "value": "5'-3\"",
      "unit": "",
      "appliesTo": "BENT 3 footing"
    },
    {
      "label": "footing edge offset",
      "value": "1'-3\"",
      "unit": "",
      "appliesTo": "BENT 3 footing"
    },
    {
      "label": "pile row edge offset",
      "value": "1'-3\"",
      "unit": "",
      "appliesTo": "BENT 3 footing"
    },
    {
      "label": "pile row spacing",
      "value": "5'-3\"",
      "unit": "",
      "appliesTo": "BENT 3 footing"
    },
    {
      "label": "pile row spacing",
      "value": "5'-3\"",
      "unit": "",
      "appliesTo": "BENT 3 footing"
    },
    {
      "label": "pile row edge offset",
      "value": "1'-3\"",
      "unit": "",
      "appliesTo": "BENT 3 footing"
    },
    {
      "label": "drawing scale",
      "value": "3/8\" = 1'-0\"",
      "unit": "",
      "appliesTo": "FOOTING PLAN - BENT 3"
    }
  ],
  "notes": [
    "2\" MIN. CL., TYP.",
    "2\" CL., 3 SIDES",
    "5-422 OR 5-432 EACH FACE"
  ],
  "labels": [
    "SECTION B-B",
    "FOOTING PLAN - BENT 3",
    "SCALE: 3/8\" = 1'-0\"",
    "℄ BRNG.",
    "℄ BENT",
    "AHEAD",
    "℄ PILE",
    "℄ BENT 2",
    "℄ BENT 3",
    "℄ COLUMN",
    "2"
  ],
  "description": "The crop shows SECTION B-B through a rectangular reinforced concrete bent-cap element, including reinforcement callouts, bearing centerlines, and bent centerline. Below it is the footing plan for Bent 3, showing a 13'-0\" by 13'-0\" rectangular footing, six pile symbols, pile layout dimensions, bent centerlines, and the column centerline."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "rectangular member",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 1,
      "note": "Shown in DETAIL 1 with reinforcement layout; SECTION A-A shows a 1'-0\" wide section."
    },
    {
      "name": "reinforcement bars",
      "tag": "5-#11",
      "shape": "straight",
      "material": "reinforcing steel",
      "count": 5,
      "note": "Five bars indicated across the member in DETAIL 1."
    },
    {
      "name": "reinforcement bars",
      "tag": "5-#14",
      "shape": "straight",
      "material": "reinforcing steel",
      "count": 10,
      "note": "Section A-A shows five bars at each face, at equal spaces."
    }
  ],
  "measurements": [
    {
      "label": "overall width",
      "value": "3'-0 7/16\"",
      "unit": "",
      "appliesTo": "rectangular member"
    },
    {
      "label": "reinforcement quantity",
      "value": "5-#11",
      "unit": "",
      "appliesTo": "reinforcement bars"
    },
    {
      "label": "reinforcement quantity",
      "value": "5-#14",
      "unit": "",
      "appliesTo": "reinforcement bars"
    },
    {
      "label": "section width",
      "value": "1'-0\"",
      "unit": "",
      "appliesTo": "rectangular member"
    }
  ],
  "notes": [
    "5-#14 EA. FACE AT EQ. SPS."
  ],
  "labels": [
    "DETAIL 1",
    "SECTION A-A",
    "A"
  ],
  "description": "This crop shows DETAIL 1 for a rectangular reinforced member and the associated SECTION A-A. The detail depicts a reinforcement grid within the member, while the section shows bars at each face and the member width."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "reinforcement bars",
      "tag": "510A",
      "shape": "straight",
      "material": "",
      "count": 5,
      "note": "Identified by printed callout \"5-510A\"; only part of the reinforcement layout is visible."
    },
    {
      "name": "reinforcement bars",
      "tag": "510B",
      "shape": "straight",
      "material": "",
      "count": 4,
      "note": "Identified by printed callout \"4-510B\"; only part of the reinforcement layout is visible."
    }
  ],
  "measurements": [
    {
      "label": "overall horizontal dimension",
      "value": "5'-4¾\"",
      "unit": "",
      "appliesTo": "visible rectangular reinforced element"
    }
  ],
  "notes": [],
  "labels": [
    "B",
    "C",
    "13A (partial)"
  ],
  "description": "This crop shows the upper portion of a rectangular reinforced-concrete detail with a visible orthogonal reinforcement grid. Section/detail direction symbols B and C are shown above the element, along with an overall horizontal dimension and reinforcement callouts 510A and 510B."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "Rectangular member",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 1,
      "note": "Only a portion of the member is shown in the crop."
    },
    {
      "name": "Reinforcement bar",
      "tag": "510A",
      "shape": "straight",
      "material": "",
      "count": 2,
      "note": "Two vertical bars are visible and are indicated by the 510A callout."
    },
    {
      "name": "Reinforcement bar",
      "tag": "#13A",
      "shape": "circular bar ends",
      "material": "",
      "count": 10,
      "note": "Shown as five bars at each face."
    }
  ],
  "measurements": [
    {
      "label": "Member width",
      "value": "1’-0”",
      "unit": "",
      "appliesTo": "Rectangular member"
    },
    {
      "label": "Reinforcement quantity and designation",
      "value": "5-#13A",
      "unit": "",
      "appliesTo": "#13A reinforcement bar"
    }
  ],
  "notes": [
    "5-#13A E.A. FACE AT EQ. SPS."
  ],
  "labels": [],
  "description": "This crop shows a reinforcement detail for a 1’-0” wide rectangular member. Five #13A bars are shown at each face at equal spaces, with two vertical bars called out as 510A; the member continues beyond the cropped detail."
}

{
  "view": "Section",
  "objects": [
    {
      "name": "concrete member",
      "tag": "",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Long narrow section with longitudinal reinforcing bars shown at two faces."
    },
    {
      "name": "reinforcement bar",
      "tag": "#13A",
      "shape": "circular",
      "material": "",
      "count": 10,
      "note": "5 bars shown at each face."
    },
    {
      "name": "reinforcement bar",
      "tag": "#13B",
      "shape": "circular",
      "material": "",
      "count": 6,
      "note": "3 bars shown at each face."
    }
  ],
  "measurements": [
    {
      "label": "section width",
      "value": "1'-0\"",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "bar quantity",
      "value": "5",
      "unit": "",
      "appliesTo": "#13A"
    },
    {
      "label": "bar quantity",
      "value": "3",
      "unit": "",
      "appliesTo": "#13B"
    }
  ],
  "notes": [
    "5-#13A E.A. FACE AT EQ. SPS.",
    "3-#13B E.A. FACE AT EQ. SPS."
  ],
  "labels": [
    "SECTION C-C"
  ],
  "description": "This crop shows SECTION C-C through a 1'-0\" wide rectangular reinforced-concrete member. Longitudinal reinforcement is shown in two vertical faces, with #13A and #13B bar groups called out at equal spacing."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "reinforcement bar",
      "tag": "5-#10A",
      "shape": "straight",
      "material": "",
      "count": 5,
      "note": "Bar callout shown at upper left portion of detail."
    },
    {
      "name": "reinforcement bar",
      "tag": "4-#10B",
      "shape": "straight",
      "material": "",
      "count": 4,
      "note": "Bar callout shown at upper right portion of detail."
    },
    {
      "name": "reinforcement bar",
      "tag": "5-#13A",
      "shape": "straight",
      "material": "",
      "count": 5,
      "note": "Bar callout shown along right side of detail."
    },
    {
      "name": "reinforcement bar",
      "tag": "3-#13B",
      "shape": "straight",
      "material": "",
      "count": 3,
      "note": "Bar callout shown along lower right side of detail."
    },
    {
      "name": "reinforcement layout boundary",
      "tag": "",
      "shape": "stepped rectangular",
      "material": "",
      "count": 1,
      "note": "Heavy outline enclosing the reinforcement grid; element type is not identified in this crop."
    }
  ],
  "measurements": [
    {
      "label": "overall horizontal dimension",
      "value": "5'-4¾\"",
      "unit": "",
      "appliesTo": "reinforcement layout boundary"
    },
    {
      "label": "reinforcement callout",
      "value": "5-#10A",
      "unit": "",
      "appliesTo": "5-#10A"
    },
    {
      "label": "reinforcement callout",
      "value": "4-#10B",
      "unit": "",
      "appliesTo": "4-#10B"
    },
    {
      "label": "reinforcement callout",
      "value": "5-#13A",
      "unit": "",
      "appliesTo": "5-#13A"
    },
    {
      "label": "reinforcement callout",
      "value": "3-#13B",
      "unit": "",
      "appliesTo": "3-#13B"
    }
  ],
  "notes": [],
  "labels": [
    "DETAIL 2",
    "B",
    "C"
  ],
  "description": "This crop shows DETAIL 2, a plan-type reinforcement layout within a stepped rectangular heavy outline. The detail includes orthogonal reinforcing-bar grids and four bar callouts, with an overall horizontal dimension of 5'-4¾\" and section/detail reference arrows B and C."
}

{
  "view": "Plan",
  "objects": [
    {
      "name": "Footing",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 1,
      "note": "Plan outline for Bent 2 footing."
    },
    {
      "name": "Pile",
      "tag": "",
      "shape": "H-section",
      "material": "",
      "count": 6,
      "note": "Six pile symbols shown within footing plan."
    },
    {
      "name": "Column",
      "tag": "",
      "shape": "",
      "material": "",
      "count": 1,
      "note": "Shown by intersecting dashed centerlines at footing center."
    },
    {
      "name": "Bent",
      "tag": "BENT 2",
      "shape": "",
      "material": "",
      "count": 1,
      "note": "Bent centerline is shown."
    }
  ],
  "measurements": [
    {
      "label": "Overall footing width",
      "value": "11'-6\"",
      "unit": "",
      "appliesTo": "Footing"
    },
    {
      "label": "Footing width segment",
      "value": "1'-3\"",
      "unit": "",
      "appliesTo": "Footing"
    },
    {
      "label": "Pile spacing",
      "value": "4'-6\"",
      "unit": "",
      "appliesTo": "Pile"
    },
    {
      "label": "Pile spacing",
      "value": "4'-6\"",
      "unit": "",
      "appliesTo": "Pile"
    },
    {
      "label": "Footing width segment",
      "value": "1'-3\"",
      "unit": "",
      "appliesTo": "Footing"
    },
    {
      "label": "Overall footing length",
      "value": "11'-6\"",
      "unit": "",
      "appliesTo": "Footing"
    },
    {
      "label": "Footing length segment",
      "value": "1'-3\"",
      "unit": "",
      "appliesTo": "Footing"
    },
    {
      "label": "Pile spacing",
      "value": "4'-6\"",
      "unit": "",
      "appliesTo": "Pile"
    },
    {
      "label": "Pile spacing",
      "value": "4'-6\"",
      "unit": "",
      "appliesTo": "Pile"
    },
    {
      "label": "Footing length segment",
      "value": "1'-3\"",
      "unit": "",
      "appliesTo": "Footing"
    },
    {
      "label": "Scale",
      "value": "3/8\" = 1'-0\"",
      "unit": "",
      "appliesTo": ""
    }
  ],
  "notes": [],
  "labels": [
    "AHEAD",
    "FOOTING PLAN - BENT 2",
    "SCALE: 3/8\" = 1'-0\""
  ],
  "description": "This crop is a footing plan for Bent 2. It shows a rectangular 11'-6\" by 11'-6\" footing, with six H-section pile symbols arranged in two lines of three and a centered column centerline."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "rectangular reinforced-concrete member",
      "tag": "",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Shown in DETAIL 3 and SECTION D-D; member depth in DETAIL 3 is not fully dimensioned in this crop."
    },
    {
      "name": "reinforcement bars",
      "tag": "5-#4",
      "shape": "straight bars",
      "material": "steel",
      "count": null,
      "note": "Callout indicates 5-#4 each face at equal spaces; section shows five bar ends at each face."
    }
  ],
  "measurements": [
    {
      "label": "overall width",
      "value": "3'-0 7/16\"",
      "unit": "",
      "appliesTo": "rectangular reinforced-concrete member"
    },
    {
      "label": "section width",
      "value": "1'-0\"",
      "unit": "",
      "appliesTo": "rectangular reinforced-concrete member"
    },
    {
      "label": "reinforcement quantity and size",
      "value": "5-#4",
      "unit": "",
      "appliesTo": "reinforcement bars"
    }
  ],
  "notes": [
    "5-#4 EA. FACE AT EQ. SPS."
  ],
  "labels": [
    "DETAIL 3",
    "SECTION D-D",
    "D"
  ],
  "description": "This crop shows DETAIL 3 of a rectangular reinforced-concrete member with a reinforcement layout. SECTION D-D shows the 1'-0\" member width and reinforcement bar ends at both faces."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "reinforcement bar",
      "tag": "540A",
      "shape": "straight",
      "material": "",
      "count": 5,
      "note": "Callout shown as \"5-540A\"."
    },
    {
      "name": "reinforcement bar",
      "tag": "540B",
      "shape": "straight",
      "material": "",
      "count": 4,
      "note": "Callout shown as \"4-540B\"."
    },
    {
      "name": "rectangular reinforcement layout",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 1,
      "note": "Only the upper portion of the layout is visible in this crop."
    }
  ],
  "measurements": [
    {
      "label": "overall horizontal dimension",
      "value": "5'-4¾\"",
      "unit": "",
      "appliesTo": "rectangular reinforcement layout"
    }
  ],
  "notes": [],
  "labels": [
    "NO SCALE",
    "E",
    "F"
  ],
  "description": "This crop shows a no-scale reinforcement detail with a rectangular grid-like bar layout, only partly visible below the crop edge. It includes section/detail reference arrows E and F, an overall horizontal dimension, and bar callouts for 540A and 540B."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "rectangular member",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 1,
      "note": "Only a portion of the member is shown in this crop."
    },
    {
      "name": "reinforcement bars",
      "tag": "#43A",
      "shape": "circular bar ends",
      "material": "reinforcing steel",
      "count": 10,
      "note": "Shown as five bar ends at each face."
    },
    {
      "name": "reinforcement bars",
      "tag": "540A",
      "shape": "straight vertical",
      "material": "reinforcing steel",
      "count": 2,
      "note": "Two vertical lines are indicated by the callout leaders."
    }
  ],
  "measurements": [
    {
      "label": "member width",
      "value": "1'-0\"",
      "unit": "",
      "appliesTo": "rectangular member"
    },
    {
      "label": "reinforcing bar quantity and spacing",
      "value": "5-#43A",
      "unit": "",
      "appliesTo": "#43A"
    }
  ],
  "notes": [
    "5-#43A E.A. FACE AT EQ. SPS."
  ],
  "labels": [],
  "description": "This crop shows a reinforcement detail for a 1'-0\" wide rectangular member. Five #43A reinforcing bars are shown at each face at equal spacing, with a 540A callout pointing to two vertical reinforcing bars."
}

{
  "view": "Section",
  "objects": [
    {
      "name": "reinforcement bar",
      "tag": "3A",
      "shape": "circular",
      "material": "",
      "count": 10,
      "note": "Called out as 5-#4 3A each face; shown in two vertical rows/faces."
    },
    {
      "name": "reinforcement bar",
      "tag": "3B",
      "shape": "circular",
      "material": "",
      "count": 6,
      "note": "Called out as 3-#4 3B each face; shown in two vertical rows/faces."
    },
    {
      "name": "rectangular member",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 1,
      "note": "Member outline shown with longitudinal reinforcement."
    }
  ],
  "measurements": [
    {
      "label": "member width",
      "value": "1'-0\"",
      "unit": "",
      "appliesTo": "rectangular member"
    },
    {
      "label": "reinforcement quantity",
      "value": "5-#4 3A",
      "unit": "",
      "appliesTo": "3A"
    },
    {
      "label": "reinforcement quantity",
      "value": "3-#4 3B",
      "unit": "",
      "appliesTo": "3B"
    }
  ],
  "notes": [
    "5-#4 3A EA. FACE AT EQ. SPS.",
    "3-#4 3B EA. FACE AT EQ. SPS."
  ],
  "labels": [
    "540B",
    "SECTION F-F"
  ],
  "description": "This crop shows Section F-F through a narrow rectangular member, 1'-0\" wide. Two faces of longitudinal reinforcement are depicted, with 3A and 3B bar groups called out at equal spacing."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "Structural member outline",
      "tag": "",
      "shape": "rectilinear stepped outline",
      "material": "",
      "count": 1,
      "note": "Element type is not labeled in this crop."
    },
    {
      "name": "Reinforcement bar",
      "tag": "540A",
      "shape": "straight vertical",
      "material": "reinforcing steel",
      "count": 5,
      "note": ""
    },
    {
      "name": "Reinforcement bar",
      "tag": "540B",
      "shape": "straight vertical",
      "material": "reinforcing steel",
      "count": 4,
      "note": ""
    },
    {
      "name": "Reinforcement bar",
      "tag": "443A",
      "shape": "straight horizontal",
      "material": "reinforcing steel",
      "count": 5,
      "note": ""
    },
    {
      "name": "Reinforcement bar",
      "tag": "443B",
      "shape": "straight horizontal",
      "material": "reinforcing steel",
      "count": 3,
      "note": ""
    }
  ],
  "measurements": [
    {
      "label": "overall horizontal dimension",
      "value": "5'-4¾\"",
      "unit": "",
      "appliesTo": "Structural member outline"
    },
    {
      "label": "reinforcement quantity and mark",
      "value": "5-540A",
      "unit": "",
      "appliesTo": "540A"
    },
    {
      "label": "reinforcement quantity and mark",
      "value": "4-540B",
      "unit": "",
      "appliesTo": "540B"
    },
    {
      "label": "reinforcement quantity and mark",
      "value": "5-443A",
      "unit": "",
      "appliesTo": "443A"
    },
    {
      "label": "reinforcement quantity and mark",
      "value": "3-443B",
      "unit": "",
      "appliesTo": "443B"
    }
  ],
  "notes": [],
  "labels": [
    "DETAIL 4",
    "E",
    "F"
  ],
  "description": "This crop shows DETAIL 4, a reinforcement layout within a rectilinear stepped structural-member outline. The detail identifies vertical reinforcement groups 540A and 540B and horizontal reinforcement groups 443A and 443B, with an overall horizontal dimension and E/F reference markers."
}

{
  "view": "Section",
  "objects": [
    {
      "name": "reinforced concrete member",
      "tag": "",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Square section with reinforcing steel shown."
    },
    {
      "name": "longitudinal reinforcing bars",
      "tag": "#21 OR #31",
      "shape": "circular",
      "material": "",
      "count": 12,
      "note": "Bars shown as solid circular section symbols."
    },
    {
      "name": "reinforcing bars",
      "tag": "#20 OR #30",
      "shape": "rectangular closed tie",
      "material": "",
      "count": 6,
      "note": "Closed perimeter tie shown."
    },
    {
      "name": "reinforcing bars",
      "tag": "#21 OR #31",
      "shape": "diagonal crosstie",
      "material": "",
      "count": 6,
      "note": "Diagonal internal tie segments shown."
    }
  ],
  "measurements": [
    {
      "label": "section width",
      "value": "3'-6\"",
      "unit": "",
      "appliesTo": "reinforced concrete member"
    },
    {
      "label": "section height",
      "value": "3'-6\"",
      "unit": "",
      "appliesTo": "reinforced concrete member"
    },
    {
      "label": "clear cover",
      "value": "2\"",
      "unit": "",
      "appliesTo": "reinforced concrete member"
    }
  ],
  "notes": [
    "2\" CL. ALL SIDES"
  ],
  "labels": [
    "SECTION C-C"
  ],
  "description": "This crop shows Section C-C through a 3'-6\" by 3'-6\" square reinforced-concrete member. The section depicts 12 longitudinal bars and two identified sets of reinforcing ties/crossties, with 2-inch clear cover on all sides."
}

{
  "view": "Plan",
  "objects": [
    {
      "name": "Bridge bent plan layout",
      "tag": "BENT 4 LEFT",
      "shape": "rectangular longitudinal layout with rounded end outlines",
      "material": "",
      "count": 1,
      "note": "Partial bent/beam layout shown; six beam centerlines are identified."
    },
    {
      "name": "Bridge bent plan layout",
      "tag": "BENT 4 RIGHT",
      "shape": "rectangular longitudinal layout with rounded end outlines",
      "material": "",
      "count": 1,
      "note": "Partial bent/beam layout shown; six beam centerlines are identified."
    },
    {
      "name": "Beam centerline locations",
      "tag": "℄ BEAM 1 through ℄ BEAM 12",
      "shape": "linear",
      "material": "",
      "count": 12,
      "note": "BEAM 1–6 are shown in the left plan and BEAM 7–12 in the right plan."
    },
    {
      "name": "Smooth dowel hole",
      "tag": "",
      "shape": "circular",
      "material": "",
      "count": null,
      "note": "Called out as formed 3 in. diameter by 12 in. deep holes for 1/2 in. diameter smooth dowels, typical."
    }
  ],
  "measurements": [
    {
      "label": "Offset dimension",
      "value": "22'-0\"",
      "unit": "",
      "appliesTo": "SR 21 WB = PCL to bent reference line"
    },
    {
      "label": "Offset dimension",
      "value": "22'-0\"",
      "unit": "",
      "appliesTo": "SR 21 EB = PCL to bent reference line"
    },
    {
      "label": "Skew angle",
      "value": "81°-20'-05.0\"",
      "unit": "",
      "appliesTo": "BENT 4 LEFT"
    },
    {
      "label": "Skew angle",
      "value": "81°-20'-05.0\"",
      "unit": "",
      "appliesTo": "BENT 4 RIGHT"
    },
    {
      "label": "Station",
      "value": "19+18.35",
      "unit": "",
      "appliesTo": "SR 21 WB = PCL"
    },
    {
      "label": "Station",
      "value": "19+15.00",
      "unit": "",
      "appliesTo": "END BRIDGE B.F.P.R. BENT 4"
    },
    {
      "label": "Typical dimension",
      "value": "81°-20'-05.0\"",
      "unit": "",
      "appliesTo": "BENT 4 LEFT"
    },
    {
      "label": "Typical dimension",
      "value": "81°-20'-05.0\"",
      "unit": "",
      "appliesTo": "BENT 4 RIGHT"
    },
    {
      "label": "Dimension",
      "value": "1'-6\"",
      "unit": "",
      "appliesTo": "B.F.P.R. / ℄ BRG. offset"
    },
    {
      "label": "Dimension",
      "value": "3'-0\"",
      "unit": "",
      "appliesTo": "BENT 4 LEFT"
    },
    {
      "label": "Dimension",
      "value": "1'-6\"",
      "unit": "",
      "appliesTo": "BENT 4 LEFT"
    },
    {
      "label": "Dimension",
      "value": "1'-6\"",
      "unit": "",
      "appliesTo": "B.F.P.R. / ℄ BRG. offset"
    },
    {
      "label": "Dimension",
      "value": "3'-0\"",
      "unit": "",
      "appliesTo": "BENT 4 RIGHT"
    },
    {
      "label": "Dimension",
      "value": "1'-6\"",
      "unit": "",
      "appliesTo": "BENT 4 RIGHT"
    },
    {
      "label": "Typical dimension",
      "value": "3¾\"",
      "unit": "",
      "appliesTo": "Beam layout"
    },
    {
      "label": "Typical beam centerline spacing",
      "value": "7'-7 7/16\"",
      "unit": "",
      "appliesTo": "Beam centerlines"
    },
    {
      "label": "End beam-layout dimension",
      "value": "3'-0 7/8\"",
      "unit": "",
      "appliesTo": "Outer beam centerline locations"
    },
    {
      "label": "Dimension",
      "value": "5'-4 1/4\"",
      "unit": "",
      "appliesTo": "End portion of each bent plan"
    },
    {
      "label": "Dimension",
      "value": "2'-9 3/4\"",
      "unit": "",
      "appliesTo": "BENT 4 LEFT"
    },
    {
      "label": "End segment dimension",
      "value": "6'-10 1/2\"",
      "unit": "",
      "appliesTo": "BENT 4 LEFT"
    },
    {
      "label": "Intermediate segment dimension",
      "value": "7'-7\"",
      "unit": "",
      "appliesTo": "BENT 4 LEFT"
    },
    {
      "label": "End segment dimension",
      "value": "6'-10 9/16\"",
      "unit": "",
      "appliesTo": "BENT 4 LEFT"
    },
    {
      "label": "Overall dimension",
      "value": "44'-1 1/16\"",
      "unit": "",
      "appliesTo": "BENT 4 LEFT"
    },
    {
      "label": "End segment dimension",
      "value": "6'-10 1/2\"",
      "unit": "",
      "appliesTo": "BENT 4 RIGHT"
    },
    {
      "label": "Intermediate segment dimension",
      "value": "7'-7\"",
      "unit": "",
      "appliesTo": "BENT 4 RIGHT"
    },
    {
      "label": "End segment dimension",
      "value": "6'-10 9/16\"",
      "unit": "",
      "appliesTo": "BENT 4 RIGHT"
    },
    {
      "label": "Overall dimension",
      "value": "44'-1 1/16\"",
      "unit": "",
      "appliesTo": "BENT 4 RIGHT"
    },
    {
      "label": "Hole diameter",
      "value": "3\"",
      "unit": "",
      "appliesTo": "Smooth dowel hole"
    },
    {
      "label": "Hole depth",
      "value": "12\"",
      "unit": "",
      "appliesTo": "Smooth dowel hole"
    },
    {
      "label": "Dowel diameter",
      "value": "1/2\"",
      "unit": "",
      "appliesTo": "Smooth dowel"
    }
  ],
  "notes": [
    "FORM 3\" DIA. X 12\" DEEP HOLE FOR 1/2\" DIA. SMOOTH DOWEL, TYP.",
    "SEE DETAIL 3 BRIDGE SHEET 16",
    "SEE DETAIL 4 BRIDGE SHEET 16"
  ],
  "labels": [
    "AHEAD",
    "SR 21 WB = PCL",
    "SR 21 EB = PCL",
    "END BRIDGE B.F.P.R. BENT 4",
    "B.F.P.R.",
    "℄ BRG.",
    "PLAN",
    "(BENT 4 LEFT)",
    "(BENT 4 RIGHT)"
  ],
  "description": "The crop contains two plan views of BENT 4, identified as BENT 4 LEFT and BENT 4 RIGHT. Each plan shows the beam centerline layout, with BEAM 1 through BEAM 12 identified across the two views, bent geometry dimensions, skew information, and dowel-hole/detail callouts."
}

{
  "view": "Elevation",
  "objects": [
    {
      "name": "horizontal reinforced-concrete member",
      "tag": "",
      "shape": "long rectangular with stepped/sloping top profile",
      "material": "",
      "count": 1,
      "note": "Extends across the crop above the pile locations."
    },
    {
      "name": "pile",
      "tag": "",
      "shape": "vertical rectangular",
      "material": "",
      "count": 6,
      "note": "Six pile locations are visible below the horizontal member; callout states 4-440 OVER EACH PILE."
    },
    {
      "name": "vertical end member",
      "tag": "",
      "shape": "vertical rectangular",
      "material": "",
      "count": 2,
      "note": "One is visible at each end of the horizontal member; identity is not labeled in this crop."
    },
    {
      "name": "reinforcement bar",
      "tag": "440",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Callout: 4-440 OVER EACH PILE."
    },
    {
      "name": "reinforcement bar",
      "tag": "441",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Callouts: 4-441 AT EQ. SPACES and 7-441 AT EQ. SPS. TYP. EA. BAY."
    },
    {
      "name": "reinforcement bar",
      "tag": "442",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Callout: 2-442."
    },
    {
      "name": "reinforcement bar",
      "tag": "445A",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Callout: 2-445A, TYP."
    },
    {
      "name": "reinforcement bar",
      "tag": "445B",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Callout: 2-445B."
    },
    {
      "name": "reinforcement bar",
      "tag": "445C",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Callout: 2-445C."
    },
    {
      "name": "reinforcement bar",
      "tag": "1040",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Callout: 4-1040."
    }
  ],
  "measurements": [
    {
      "label": "elevation",
      "value": "EL. 189.42",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "elevation",
      "value": "EL. 189.50",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "elevation",
      "value": "EL. 186.04",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "elevation",
      "value": "EL. 185.93",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "elevation",
      "value": "EL. 185.80",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "elevation",
      "value": "EL. 185.67",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "elevation",
      "value": "EL. 185.53",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "elevation",
      "value": "EL. 185.37",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "elevation",
      "value": "EL. 184.04",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "elevation",
      "value": "EL. 183.25",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "elevation",
      "value": "EL. 188.67",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "elevation",
      "value": "EL. 188.71",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "reinforcement quantity",
      "value": "4-440",
      "unit": "",
      "appliesTo": "440"
    },
    {
      "label": "reinforcement quantity",
      "value": "2-442",
      "unit": "",
      "appliesTo": "442"
    },
    {
      "label": "reinforcement quantity",
      "value": "4-1040",
      "unit": "",
      "appliesTo": "1040"
    },
    {
      "label": "reinforcement quantity",
      "value": "2-445A",
      "unit": "",
      "appliesTo": "445A"
    },
    {
      "label": "reinforcement quantity",
      "value": "2-445B",
      "unit": "",
      "appliesTo": "445B"
    },
    {
      "label": "reinforcement quantity",
      "value": "2-445C",
      "unit": "",
      "appliesTo": "445C"
    },
    {
      "label": "reinforcement quantity",
      "value": "4-441",
      "unit": "",
      "appliesTo": "441"
    },
    {
      "label": "reinforcement quantity",
      "value": "7-441",
      "unit": "",
      "appliesTo": "441"
    },
    {
      "label": "spacing",
      "value": "10”",
      "unit": "",
      "appliesTo": "pile locations"
    },
    {
      "label": "spacing",
      "value": "10”",
      "unit": "",
      "appliesTo": "pile locations"
    },
    {
      "label": "length",
      "value": "2’-10⅛”",
      "unit": "",
      "appliesTo": "left end segment"
    },
    {
      "label": "bay spacing",
      "value": "7’-7¹⁄₁₆”",
      "unit": "",
      "appliesTo": "bay"
    },
    {
      "label": "bay spacing",
      "value": "7’-7¹⁄₁₆”",
      "unit": "",
      "appliesTo": "bay"
    },
    {
      "label": "bay spacing",
      "value": "7’-7¹⁄₁₆”",
      "unit": "",
      "appliesTo": "bay"
    },
    {
      "label": "bay spacing",
      "value": "7’-7¹⁄₁₆”",
      "unit": "",
      "appliesTo": "bay"
    },
    {
      "label": "length",
      "value": "3’-3⅝”",
      "unit": "",
      "appliesTo": "right end segment"
    },
    {
      "label": "overall length",
      "value": "44’-1¹⁄₁₆”",
      "unit": "",
      "appliesTo": "horizontal member"
    }
  ],
  "notes": [
    "4-440 OVER EACH PILE",
    "4-441 AT EQ. SPACES",
    "7-441 AT EQ. SPS. TYP. EA. BAY",
    "2-445A, TYP."
  ],
  "labels": [
    "A",
    "B",
    "ELEVATION"
  ],
  "description": "This crop shows an elevation of a long horizontal structural member supported at six visible pile locations. Reinforcement callouts, elevations, pile/bay spacing, end-segment dimensions, and an overall length are shown; the drawing title is cropped, with only “ELEVATION” visible."
}

{
  "view": "Elevation",
  "objects": [
    {
      "name": "horizontal structural member",
      "tag": "",
      "shape": "long rectangular member with stepped top profile",
      "material": "",
      "count": 1,
      "note": "Extends between the two end vertical members; internal reinforcement is shown."
    },
    {
      "name": "pile",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 6,
      "note": "Six vertical piles/supports are visible below the horizontal member; callout states 4-440 over each pile."
    },
    {
      "name": "end vertical member",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 2,
      "note": "One upright member is shown at each end of the elevation."
    },
    {
      "name": "reinforcing bar",
      "tag": "440",
      "shape": "straight",
      "material": "steel",
      "count": null,
      "note": "Called out as 4-440 OVER EACH PILE."
    },
    {
      "name": "reinforcing bar",
      "tag": "441",
      "shape": "straight",
      "material": "steel",
      "count": null,
      "note": "Called out at equal spaces, typical each bay, and at equal spaces at the ends."
    },
    {
      "name": "reinforcing bar",
      "tag": "442",
      "shape": "straight",
      "material": "steel",
      "count": 2,
      "note": ""
    },
    {
      "name": "reinforcing bar",
      "tag": "1040",
      "shape": "straight",
      "material": "steel",
      "count": 4,
      "note": ""
    },
    {
      "name": "reinforcing bar",
      "tag": "445A",
      "shape": "straight",
      "material": "steel",
      "count": 2,
      "note": "TYP."
    },
    {
      "name": "reinforcing bar",
      "tag": "445B",
      "shape": "straight",
      "material": "steel",
      "count": 2,
      "note": ""
    },
    {
      "name": "reinforcing bar",
      "tag": "445C",
      "shape": "straight",
      "material": "steel",
      "count": 2,
      "note": ""
    }
  ],
  "measurements": [
    {
      "label": "Elevation",
      "value": "EL. 188.39",
      "unit": "",
      "appliesTo": "left end vertical member"
    },
    {
      "label": "Elevation",
      "value": "EL. 188.45",
      "unit": "",
      "appliesTo": "left end vertical member"
    },
    {
      "label": "Elevation",
      "value": "EL. 185.12",
      "unit": "",
      "appliesTo": "horizontal structural member"
    },
    {
      "label": "Elevation",
      "value": "EL. 185.32",
      "unit": "",
      "appliesTo": "horizontal structural member"
    },
    {
      "label": "Elevation",
      "value": "EL. 185.49",
      "unit": "",
      "appliesTo": "horizontal structural member"
    },
    {
      "label": "Elevation",
      "value": "EL. 185.66",
      "unit": "",
      "appliesTo": "horizontal structural member"
    },
    {
      "label": "Elevation",
      "value": "EL. 185.82",
      "unit": "",
      "appliesTo": "horizontal structural member"
    },
    {
      "label": "Elevation",
      "value": "EL. 185.96",
      "unit": "",
      "appliesTo": "horizontal structural member"
    },
    {
      "label": "Elevation",
      "value": "EL. 189.36",
      "unit": "",
      "appliesTo": "right end vertical member"
    },
    {
      "label": "Elevation",
      "value": "EL. 189.44",
      "unit": "",
      "appliesTo": "right end vertical member"
    },
    {
      "label": "Elevation",
      "value": "EL. 182.96",
      "unit": "",
      "appliesTo": "left end of horizontal structural member"
    },
    {
      "label": "Elevation",
      "value": "EL. 183.96",
      "unit": "",
      "appliesTo": "right end of horizontal structural member"
    },
    {
      "label": "Typical dimension",
      "value": "10″",
      "unit": "",
      "appliesTo": "pile locations"
    },
    {
      "label": "Left end segment dimension",
      "value": "2′-10⅞″",
      "unit": "",
      "appliesTo": "horizontal structural member"
    },
    {
      "label": "Repeated bay dimension",
      "value": "7′-7¹⁄₁₆″",
      "unit": "",
      "appliesTo": "horizontal structural member"
    },
    {
      "label": "Right end segment dimension",
      "value": "3′-3⅝″",
      "unit": "",
      "appliesTo": "horizontal structural member"
    },
    {
      "label": "Overall dimension",
      "value": "44′-1¹⁄₁₆″",
      "unit": "",
      "appliesTo": "horizontal structural member"
    },
    {
      "label": "Reinforcing-bar quantity",
      "value": "4",
      "unit": "",
      "appliesTo": "440"
    },
    {
      "label": "Reinforcing-bar quantity",
      "value": "2",
      "unit": "",
      "appliesTo": "442"
    },
    {
      "label": "Reinforcing-bar quantity",
      "value": "4",
      "unit": "",
      "appliesTo": "1040"
    },
    {
      "label": "Reinforcing-bar quantity",
      "value": "2",
      "unit": "",
      "appliesTo": "445A"
    },
    {
      "label": "Reinforcing-bar quantity",
      "value": "2",
      "unit": "",
      "appliesTo": "445B"
    },
    {
      "label": "Reinforcing-bar quantity",
      "value": "2",
      "unit": "",
      "appliesTo": "445C"
    },
    {
      "label": "Reinforcing-bar quantity",
      "value": "7",
      "unit": "",
      "appliesTo": "441"
    },
    {
      "label": "Reinforcing-bar quantity",
      "value": "4",
      "unit": "",
      "appliesTo": "441"
    }
  ],
  "notes": [
    "4-440 OVER EACH PILE",
    "2-442",
    "4-1040",
    "2-445A, TYP.",
    "2-445B",
    "2-445C",
    "7-441 AT EQ. SPS. TYP. EA. BAY",
    "4-441 AT EQ. SPACES"
  ],
  "labels": [
    "A",
    "B",
    "ELEVATION"
  ],
  "description": "This crop shows an elevation of a long stepped-top horizontal structural member supported by six visible rectangular piles, with upright vertical members at both ends. Reinforcement callouts, elevations, pile/bay spacing, end dimensions, and an overall length are shown; section-reference arrows A and B are also visible."
}

{
  "view": "Notes",
  "objects": [],
  "measurements": [
    {
      "label": "reinforcement clearance",
      "value": "2”",
      "unit": "",
      "appliesTo": "reinforcement"
    }
  ],
  "notes": [
    "NOTES:",
    "1. MAINTAIN 2” CLEARANCE ON ALL REINFORCEMENT UNLESS OTHERWISE NOTED.",
    "2. SEE GA. STD. 9037 FOR DRAINAGE DETAILS AT END BENTS."
  ],
  "labels": [],
  "description": "This crop contains general construction notes. It specifies reinforcement clearance and refers to GA. STD. 9037 for drainage details at end bents."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "cap",
      "tag": "CAP",
      "shape": "rectangular with chamfered corners",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "vertical support members",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 2,
      "note": "Shown extending below the cap; lower portions are broken off."
    },
    {
      "name": "connecting member",
      "tag": "",
      "shape": "stepped/tapered profile",
      "material": "",
      "count": 1,
      "note": "Connects the cap area to the wall area."
    },
    {
      "name": "wall",
      "tag": "",
      "shape": "rectangular vertical stem with rectangular block at upper portion",
      "material": "",
      "count": 1,
      "note": "Callout identifies the front of wall; text is cropped."
    }
  ],
  "measurements": [
    {
      "label": "minimum horizontal distance from B.F.P.R. to wall reference line",
      "value": "6'-0\" MIN.",
      "unit": "",
      "appliesTo": "wall"
    },
    {
      "label": "horizontal cap dimension",
      "value": "3'-0\"",
      "unit": "",
      "appliesTo": "CAP"
    },
    {
      "label": "minimum vertical cap dimension",
      "value": "2'-0\" MIN.",
      "unit": "",
      "appliesTo": "CAP"
    }
  ],
  "notes": [],
  "labels": [
    "B.F.P.R.",
    "C... (partial)",
    "FRONT OF WA... (partial)"
  ],
  "description": "This crop shows a structural detail with a rectangular CAP supported by two vertical members and connected by a stepped profile to a wall element. The crop documents minimum cap dimensions and a 6-foot minimum horizontal relationship from the B.F.P.R. reference to the wall reference line."
}

{
  "view": "Section",
  "objects": [
    {
      "name": "reinforced concrete member",
      "tag": "",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Sectioned member is 3'-0\" wide and 2'-0\" minimum deep as dimensioned."
    },
    {
      "name": "reinforcing bars",
      "tag": "#42",
      "shape": "circular",
      "material": "steel",
      "count": 2,
      "note": "Two top bars indicated by callout 2-#42."
    },
    {
      "name": "reinforcing bars",
      "tag": "#40",
      "shape": "circular",
      "material": "steel",
      "count": 4,
      "note": "Four bars indicated by callout 4-#40, with corner bars shown."
    },
    {
      "name": "central vertical member",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 1,
      "note": "Member continues below the sectioned concrete member; identity is not labeled in this crop."
    }
  ],
  "measurements": [
    {
      "label": "overall width",
      "value": "3'-0\"",
      "unit": "",
      "appliesTo": "reinforced concrete member"
    },
    {
      "label": "half-width spacing",
      "value": "1'-6\"",
      "unit": "",
      "appliesTo": "reinforced concrete member"
    },
    {
      "label": "half-width spacing",
      "value": "1'-6\"",
      "unit": "",
      "appliesTo": "reinforced concrete member"
    },
    {
      "label": "minimum clear cover",
      "value": "2\" MIN. CL.",
      "unit": "",
      "appliesTo": "reinforced concrete member"
    },
    {
      "label": "minimum depth",
      "value": "2'-0\" MIN.",
      "unit": "",
      "appliesTo": "reinforced concrete member"
    },
    {
      "label": "typical vertical dimension",
      "value": "1'-0\" TYP.",
      "unit": "",
      "appliesTo": "reinforced concrete member"
    },
    {
      "label": "clear cover, three sides",
      "value": "2\" CL. 3 SIDES",
      "unit": "",
      "appliesTo": "central vertical member"
    },
    {
      "label": "half-width spacing",
      "value": "1'-6\"",
      "unit": "",
      "appliesTo": "central vertical member"
    },
    {
      "label": "half-width spacing",
      "value": "1'-6\"",
      "unit": "",
      "appliesTo": "central vertical member"
    },
    {
      "label": "drawing scale",
      "value": "3/4\" = 1'-0\"",
      "unit": "",
      "appliesTo": "SECTION A-A"
    }
  ],
  "notes": [],
  "labels": [
    "SECTION A-A",
    "SCALE: 3/4\" = 1'-0\""
  ],
  "description": "This crop shows SECTION A-A through a rectangular reinforced-concrete member with reinforcing bars and cover dimensions. A central rectangular vertical member is shown extending below the sectioned member, but it is not identified in this crop."
}
