gdot_drawing-83a3db2262b94086918a1e232d2b9607 · Bridge

Models

Step 1 sends drawing crops, so it needs a model that can see them. Steps 2 and 3 send step 1’s readings as text — a text-only model with a large context is a fair answer there.

1Read the crops304 crops · all read · 1336 objects · 4531 measurementsconfigured openai/gpt-5.6-terra-pro · about $1.73 for 304 crops · default

Every cropped image from the cropping run, page by page, with what the model read off it: view, objects, measurements, notes and labels. Click a crop to see it beside its JSON.

All 304 crops read.

304crops304read1336objects found4531measurements3,769,924tokens in1,185,838tokens out
Page 95 crops · 5 read
item · 1097 × 1429

Other P09 R03

page 9 · other_p09_r03
Original
Other P09 R03
{
  "view": "Section",
  "objects": [
    {
      "name": "edge beam",
      "tag": "",
      "shape": "stepped rectangular",
      "material": "",
      "count": 1,
      "note": "Shown in section."
    },
    {
      "name": "deck slab",
      "tag": "",
      "shape": "rectangular",
      "material": "",
      "count": 1,
      "note": "Slab reinforcement not shown."
    },
    {
      "name": "construction joint",
      "tag": "",
      "shape": "vertical joint",
      "material": "",
      "count": 1,
      "note": "Required construction joint at center of section."
    },
    {
      "name": "preformed joint filler",
      "tag": "*",
      "shape": "vertical strip",
      "material": "",
      "count": 1,
      "note": "Called out as 1-inch preformed joint filler."
    },
    {
      "name": "reinforcement bar",
      "tag": "506A",
      "shape": "bent bar",
      "material": "",
      "count": null,
      "note": "Called out at 18-inch spacing."
    },
    {
      "name": "reinforcement bar",
      "tag": "2-800",
      "shape": "bent bar",
      "material": "",
      "count": 2,
      "note": ""
    },
    {
      "name": "reinforcement bar",
      "tag": "508",
      "shape": "bent bar",
      "material": "",
      "count": null,
      "note": ""
    },
    {
      "name": "reinforcement bar",
      "tag": "509",
      "shape": "bent bar",
      "material": "",
      "count": null,
      "note": ""
    },
    {
      "name": "reinforcement bar",
      "tag": "1-801",
      "shape": "bar",
      "material": "",
      "count": null,
      "note": ""
    },
    {
      "name": "reinforcement bar",
      "tag": "1-802",
      "shape": "bar",
      "material": "",
      "count": null,
      "note": ""
    },
    {
      "name": "reinforcement bar",
      "tag": "404",
      "shape": "bar",
      "material": "",
      "count": null,
      "note": ""
    }
  ],
  "measurements": [
    {
      "label": "bar spacing",
      "value": "18”",
      "unit": "",
      "appliesTo": "506A"
    },
    {
      "label": "horizontal dimension",
      "value": "8”",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "horizontal dimension",
      "value": "1’-0½”",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "horizontal dimension",
      "value": "1’-0½”",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "horizontal dimension",
      "value": "8”",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "clear cover",
      "value": "4”",
      "unit": "",
      "appliesTo": "2-800"
    },
    {
      "label": "vertical dimension",
      "value": "8”",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "clear dimension, 3 sides",
      "value": "1½”",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "horizontal dimension",
      "value": "1’-0”",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "horizontal dimension",
      "value": "1’-0”",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "preformed joint filler thickness",
      "value": "1”",
      "unit": "",
      "appliesTo": "*"
    },
    {
      "label": "vertical dimension",
      "value": "3’-0”",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "vertical dimension",
      "value": "2”",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "scale",
      "value": "¾” = 1’-0”",
      "unit": "",
      "appliesTo": "SECTION THRU EDGE BEAM"
    }
  ],
  "notes": [
    "SEE DETAIL “A”",
    "REQ’D. CONST. JOINT",
    "*1” PREFORMED JOINT FILLER",
    "BEARING PADS NOT SHOWN",
    "SLAB REINFORCEMENT NOT SHOWN",
    "BENT 2 SHOWN",
    "BENT 3 SIMILAR"
  ],
  "labels": [
    "SECTION THRU EDGE BEAM",
    "SCALE: ¾” = 1’-0”"
  ],
  "description": "This crop is a section through an edge beam at a required construction joint. It shows the deck slab and edge beam geometry, joint filler, and reinforcing-bar callouts; bearing pads and slab reinforcement are specifically noted as not shown."
}

Other P09 R03

done

other_p09_r03

Section11 objects · 14 measurements · 7 notes · 2 labels

This crop is a section through an edge beam at a required construction joint. It shows the deck slab and edge beam geometry, joint filler, and reinforcing-bar callouts; bearing pads and slab reinforcement are specifically noted as not shown.

Objects · 11

MarkObjectNo.ShapeNote
edge beam1stepped rectangularShown in section.
deck slab1rectangularSlab reinforcement not shown.
construction joint1vertical jointRequired construction joint at center of section.
*preformed joint filler1vertical stripCalled out as 1-inch preformed joint filler.
506Areinforcement barbent barCalled out at 18-inch spacing.
2-800reinforcement bar2bent bar
508reinforcement barbent bar
509reinforcement barbent bar
1-801reinforcement barbar
1-802reinforcement barbar
404reinforcement barbar

Measurements · 14

MeasurementValueApplies to
bar spacing18”506A
horizontal dimension8”
horizontal dimension1’-0½”
horizontal dimension1’-0½”
horizontal dimension8”
clear cover4”2-800
vertical dimension8”
clear dimension, 3 sides1½”
horizontal dimension1’-0”
horizontal dimension1’-0”
preformed joint filler thickness1”*
vertical dimension3’-0”
vertical dimension2”
scale¾” = 1’-0”SECTION THRU EDGE BEAM

Labels

SECTION THRU EDGE BEAMSCALE: ¾” = 1’-0”

Notes

  • SEE DETAIL “A”
  • REQ’D. CONST. JOINT
  • *1” PREFORMED JOINT FILLER
  • BEARING PADS NOT SHOWN
  • SLAB REINFORCEMENT NOT SHOWN
  • BENT 2 SHOWN
  • BENT 3 SIMILAR
